Emerson Rosemount 3051S ERS User Manual

109
Specifications and Reference Data
Specifications and Reference Data
November 2016
Reference Manual
00809-0100-4804, Rev CB
A.6 Spare parts
Sensor modules
See Rosemount 3051S_C, 3051S_T, and 3051SAL_C ordering tables in the Rosemount 3051S Product Data Sheet for ordering spare
Rosemount 3051S sensor modules. Use housing code style 00 in the model number.
• Example model number: 3051S1CG4A2000A00
Housing assemblies
See Table A-14 on page 106 for ordering spare housing assemblies.
• Example model number: 300ERSP1AAM5
Electronics board (ERS primary unit only)
Rosemount 3051S ERS electronics feature board kit 03151-9028-0001
Rosemount 3051S ERS electronics feature board kit for remote display housing 03151-9028-0002
LCD display (ERS primary unit only)
LCD display with extended aluminum housing cover 00753-9004-0001
LCD display with extended SST housing cover 00753-9004-0004
LCD display only 00753-9004-0002
Aluminum housing cover for LCD display 00753-9004-0003
SST housing cover for LCD display 00753-9004-0005
Terminal blocks
Terminal block for ERS primary unit 03151-9006-1001
Transient terminal block for ERS primary unit 03151-9006-1002
Terminal block for ERS secondary unit 03151-9000-3001
Covers
Aluminum electronics cover and O-ring 03151-9030-0001
316L SST electronics cover and O-ring 03151-9030-0002
Miscellaneous housing parts
External ground screw assembly (Option D4): screw, clamp, washer 03151-9060-0001
Housing V-seal (for both PlantWeb and Junction box housings) 03151-9061-0001
Flanges (for gage/absolute sensor)
Coplanar flange: Nickel-plated carbon steel 03151-9200-1025
Coplanar flange: 316 SST 03151-9200-1022
Coplanar flange: Cast C-276 03151-9200-1023
Coplanar flange: Cast Alloy 400 03151-9200-1024
Coplanar flange alignment screw (package of 12) 03151-9202-0001
Traditional flange: 316 SST 03151-9203-0002
Traditional flange: Cast C-276 03151-9203-0003
Traditional flange: Cast Alloy 400 03151-9203-0004
Level flange, vertical mount: 2-in. Class 150, SST 03151-9205-0221
Level flange, vertical mount: 2-in. Class 300, SST 03151-9205-0222
Level flange, vertical mount: 3-in. Class 150, SST 03151-9205-0231
Level flange, vertical mount: 3-in. Class 300, SST 03151-9205-0232
Level flange, vertical mount: DN 50, PN 40 03151-9205-1002
Level flange, vertical mount: DN 80, PN 40 03151-9205-1012

Emerson Rosemount 3051S ERS Specifications

General

Model	3051S ERS
Category	Accessories
Operating Temperature	-40 to 85°C (-40 to 185°F)
Transmitter Compatibility	Rosemount 3051S
Communication Protocol	HART
Housing Material	Stainless Steel
Compatibility	Rosemount 3051S
Enclosure Rating	NEMA 4X
Product Type	Electronic Remote Sensor (ERS) System
