38
Reference Manual
00809-0100-4804, Rev CB
Configuration
November 2016
Configuration
3.5.6 Process alerts
Process alerts allow for the configuration of the ERS System to output a HART message when a
parameter (such as the measured DP) exceeds a user-defined operating window. An alert will be
communicated to the HART host (such as a Field Communicator or AMS Device Manager) when polled,
and on the LCD display of the ERS System. The alert will reset once the value returns within range.
Process alerts may be configured for the following parameters:
 Differential pressure
 P
HI
pressure
 P
LO
pressure
 P
HI
module temperature
 P
LO
module temperature
Configure process alerts
1. Select a parameter for which the process alert will be configured.
2. Set the Alert Mode to “enable.”
3. Define the low alert value. If the measured value for the parameter goes below the low alert value, an
alert message will be generated.
4. Define the high alert value. if the measured value for the parameter goes above the high alert value,
an alert message will be generated.
Disable process alerts
1. Select a parameter for which the process alert will be disabled.
2. Set the Alert Mode to “disabled.”
Fast Keys
2, 3
