Emerson Rosemount 3051S ERS User Manual

Specifications and Reference Data
November 2016
Reference Manual
00809-0100-4804, Rev CB
68
Specifications and Reference Data
A.2 Functional specifications
A.2.2 Minimum span limits
DP span considerations
Consult with your Emerson Sales Representative or Instrument
Toolkit when considering a Rosemount 3051S ERS System for use
on applications beyond 100:1 rangedown (operating pressure/DP
span).
A.2.1 Range and sensor limits
Coplanar gage sensor (Rosemount 3051SAM_ _G, Rosemount
3051SAL _ _G)
Lower range limit (LRL)
(1)
1. Assumes atmospheric pressure of 14.7 psig (1 bar).
Upper range limit (URL)
Range 2 –250 inH
2
O (–623 mbar) 250 inH
2
O (623 mbar)
Range 3 –393 inH
2
O (–979 mbar) 1000 in.inH
2
O (2,49 bar)
Range 4 –14.2 psig (–979 mbar) 300 psig (20,7 bar)
Range 5 –14.2 psig (–979 mbar) 2000 psig (137,9 bar)
Coplanar absolute sensor (Rosemount 3051SAM_ _A,
Rosemount 3051SAL_ _A)
Lower range limit (LRL) Upper range limit (URL)
Range 1 0 psia (0 bar) 30 psia (2,07 bar)
Range 2 0 psia (0 bar) 150 psia (10,34 bar)
Range 3 0 psia (0 bar) 800 psia (55,16 bar)
Range 4 0 psia (0 bar) 4000 psia (275,8 bar)
In-Line gage sensor (Rosemount 3051SAM_ _T, Rosemount
3051SAL _ _T)
Lower range limit (LRL)
(1)
Upper range limit (URL)
Range 1 –14.7 psig (–1 bar) 30 psig (2,07 bar)
Range 2 –14.7 psig (–1 bar) 150 psig (10,34 bar)
Range 3 –14.7 psig (–1 bar) 800 psig (55,16 bar)
Range 4 –14.7 psig (–1 bar) 4000 psig (275,8 bar)
Range 5 –14.7 psig (–1 bar) 10000 psig (689,5 bar)
In-Line absolute sensor (Rosemount 3051SAM_ _E, Rosemount
3051SAL _ _E)
Lower range limit (LRL) Upper range limit (URL)
Range 1 0 psia (0 bar) 30 psia (2,07 bar)
Range 2 0 psia (0 bar) 150 psia (10,34 bar)
Range 3 0 psia (0 bar) 800 psia (55,16 bar)
Range 4 0 psia (0 bar) 4000 psia (275,8 bar)
Range 5 0 psia (0 bar) 10000 psia (689,5 bar)
Table A-3. Minimum Calibrated Span for Each Sensor
The values shown below are the minimum calibrated spans for
each pressure sensor range.
Coplanar gage sensor (Rosemount 3051SAM_ _G,
Rosemount 3051SAL _ _G
(1)
)
1. Use “Classic” specification regardless of specified performance class.
Ultra Classic
Range 2 1.3 inH
2
O (3,11 mbar) 2.5 inH
2
O (6,23 mbar)
Range 3 5.0 inH
2
O (12,4 mbar) 10.0 inH
2
O (24,9 mbar)
Range 4 1.5 psig (103,4 mbar) 3.0 psig (206,8 mbar)
Range 5 10.0 psig (689,5 mbar) 20.0 psig (1,38 bar)
Coplanar absolute sensor (Rosemount 3051SAM_ _A,
Rosemount 3051SAL_ _A
(1)
)
Ultra Classic
Range 1 0.3 psia (20,7 mbar) 0.3 psia (20,7 mbar)
Range 2 0.75 psia (51,7 mbar) 1.5 psia (103,4 mbar)
Range 3 4 psia (275,8 mbar) 8 psia (0,55 bar)
Range 4 20 psia (275,8 mbar) 40 psia (2,76 bar)
In-Line gage sensor (Rosemount 3051SAM_ _T, Rosemount
3051SAL _ _T
(1)
)
Ultra Classic
Range 1 0.3 psig (20,7 mbar) 0.3 psig (20,7 mbar)
Range 2 0.75 psig (51,7 mbar) 1.5 psig (103,4 mbar)
Range 3 4 psig (275,8 mbar) 8 psig (0,55 bar)
Range 4 20 psig (1,38 bar) 40 psig (2,76 bar)
Range 5 1000 psig (68,9 bar) 2000 psig (137,9 bar)
In-Line absolute sensor (Rosemount 3051SAM_ _E,
Rosemount 3051SAL _ _E
(1)
)
Ultra Classic
Range 1 0.3 psia (20,7 mbar) 0.3 psia (20,7 mbar)
Range 2 0.75 psia (51,7 mbar) 1.5 psia (103,4 mbar)
Range 3 4 psia (275,8 mbar) 8 psia (0,55 bar)
Range 4 20 psia (275,8 mbar) 40 psia (2,76 bar)
Range 5 1000 psia (68,9 bar) 2000 psia (137,9 bar)

Emerson Rosemount 3051S ERS Specifications

General

Model	3051S ERS
Category	Accessories
Operating Temperature	-40 to 85°C (-40 to 185°F)
Transmitter Compatibility	Rosemount 3051S
Communication Protocol	HART
Housing Material	Stainless Steel
Compatibility	Rosemount 3051S
Enclosure Rating	NEMA 4X
Product Type	Electronic Remote Sensor (ERS) System
