Specifications and Reference Data
November 2016
Reference Manual
00809-0100-4804, Rev CB
72
Specifications and Reference Data
A.3.4 Process wetted parts
Process isolating diaphragms
Drain/vent valves
316 SST, Alloy C-276, or Alloy 400/K-500 material (drain/vent seat:
Alloy 400, drain/vent stem: Alloy K-500)
Process flanges and adapters
Plated carbon steel
SST: CF-8M (Cast 316 SST) per ASTM A743
Cast C-276: CW-12MW per ASTM A494
Cast Alloy 400: M-30C per ASTM A494
Wetted O-rings
Glass-filled PTFE, Graphite-filled PTFE (used only with gold-plated
alloy 400 isolating diaphragm)
A.3.5 Non-wetted parts
Electronics housing
Low-copper aluminum alloy or CF-8M (Cast 316 SST)
NEMA
®
4X, IP 66, IP 68
Coplanar sensor module housing
SST: CF-3M (Cast 316L SST)
Bolts
Plated carbon steel per ASTM A449, Type 1
Austenitic 316 SST per ASTM F593
ASTM A453, Class D, Grade 660 SST
ASTM A193, Grade B7M alloy steel
ASTM A193, Class 2, Grade B8M SST
Alloy K-500
Sensor module fill fluid
Silicone or Inert (halocarbon)
Seal fill fluid (Rosemount 3051SAL Liquid Level Sensor)
Silicone 200, D.C. Silicone 704, SYLTHERM
™
XLT, Inert
(halocarbon), Glycerin and water, Neobee
®
M-20, Propylene
Glycol, and Water
Paint
Polyurethane
Cover O-rings
Buna-N
Coplanar gage/absolute sensor (Rosemount 3051SAM_ _G,
Rosemount 3051SAL _ _A)
316L SST (UNS S31603), Alloy C-276 (UNS N10276), Alloy 400 (UNS
N04400), Tantalum (UNS R05440), Gold-Plated Alloy 400, Gold-Plated
316L SST
In-Line gage sensor/absolute (Rosemount 3051SAM_ _T,
Rosemount 3051SAL _ _E)
316L SST (UNS S31603), Alloy C-276 (UNS N10276)
Liquid level sensor (Rosemount 3051SAL)
FF Seal
316L SST, Alloy C-276, Tantalum
EF Seal
RF Seal
RT Seal
SC Seal
316L SST, Alloy C-276
SS Seal
