Product Certifications
November 2016
Reference Manual
00809-0100-4804, Rev CB
116
Product Certifications
Special Conditions for Safe Use (X):
1. The Rosemount 3051S Transmitters fitted with transient
protection are not capable of withstanding the 500V test as
defined in Clause 6.3.13 of EN 60079-11:2012. This must be
taken into account during installation.
2. The terminal pins of the Rosemount 3051S SuperModule
must be provided with a degree of protection of at least IP20
in accordance with IEC/EN 60529.
3. The Rosemount 3051S enclosure may be made of aluminum
alloy and given a protective polyurethane paint finish;
however, care should be taken to protect it from impact or
abrasion if located in a zone 0 area.
I7 IECEx Intrinsic Safety – Group I - Mining (I7 with Special
A0259)
Certificate: IECEx TSA 14.0019X
Standards: IEC 60079-0: 2011, IEC 60079-11: 2011
Markings: Ex ia I Ma (–60 °C
Ta +70 °C)
Special Conditions for Safe Use (X):
1. If the apparatus is fitted with optional 90 V transient
suppressor, it is not capable of withstanding the 500 V
insulation test required by IEC60079-11. This must be taken
into account when installing the apparatus.
2. It is a condition of safe use that the above table input
parameters shall be taken into account during installation.
3. It is a condition of manufacture that only the apparatus fitted
with housing, covers and sensor module housing made out
of stainless steel are used in Group I applications.
IG IECEx FISCO
Certificate: IECEx BAS 04.0017X
Standards: IEC 60079-0: 2011, IEC 60079-11: 2011
Markings: Ex ia IIC T4 Ga, T4(–60 °C
Ta +70 °C)
Special Conditions for Safe Use (X):
1. The Rosemount 3051S Transmitters fitted with transient
protection are not capable of withstanding the 500V test as
defined in Clause 6.3.13 of EN 60079-11:2012. This must be
taken into account during installation.
2. The terminal pins of the Rosemount 3051S SuperModule
must be provided with a degree of protection of at least IP20
in accordance with IEC/EN 60529.
3. The Rosemount 3051S enclosure may be made of aluminum
alloy and given a protective polyurethane paint finish;
however, care should be taken to protect it from impact or
abrasion if located in a zone 0 area.
N7 IECEx Type n
Certificate: IECEx BAS 04.0018X
Standards: IEC 60079-0: 2011, IEC 60079-15: 2010
Markings: Ex nA IIC T5 Gc, (–40 °C
Ta +85 °C)
Special Condition for Safe Use (X):
1. The equipment is not capable of withstanding the 500V
insulation test required by clause 6.5 of EN 60079-15:2010.
This must be taken into account when installing the
equipment.
B.8 Brazil
E2 INMETRO Flameproof
Certificate: UL-BR15.0393X
Standards: ABNT NBR IEC 60079-0:2008 + Corrigendum
1:2011, ABNT NBR IEC 60079-1:2009 +
Corrigendum 1:2011, ABNT NBR IEC
60079-26:2008 + Corrigendum 1: 2008
Markings: Ex d IIC T* Ga/Gb, T6(–60 °C
Ta +70 °C),
T5/T4(–60 °C
Ta +80 °C), IP66
U
i
I
i
P
i
C
i
L
i
SuperModule 30V 300 mA 1.0 W 30 nF 0
3051S...A; 3051SF…A;
3051SAL…C
30V 300 mA 1.0 W 12 nF 0
3051S…F; 3051SF…F 30V 300 mA 1.3 W 0 0
3051S …A…M7, M8, or M9;
3051SF …A…M7, M8, or M9;
3051SAL…C… M7, M8, or M9
30V 300 mA 1.0 W 11.4nF 60 H
3051SAL or 3051SAM 30V 300 mA 1.0 W 11.4nF 33 H
3051SAL…M7, M8, or M9
3051SAM…M7, M8, or M9
30V 300 mA 1.0 W 11.4nF 93 H
RTD Option for 3051SF 5V 500 mA 0.63 W N/A N/A
U
i
I
i
P
i
C
i
L
i
SuperModule 30V 300 mA 1.0 W 30 nF 0
3051S...A; 3051SF…A;
3051SAL…C
30V 300 mA 1.0 W 12 nF 0
3051S…F; 3051SF…F 30V 300 mA 1.3 W 0 0
3051S …A…M7, M8, or M9;
3051SF …A…M7, M8, or M9;
3051SAL…C… M7, M8, or M9
30V 300 mA 1.0 W 11.4nF 60 H
3051SAL or 3051SAM 30V 300 mA 1.0 W 11.4nF 33 H
3051SAL…M7, M8, or M9
3051SAM…M7, M8, or M9
30V 300 mA 1.0 W 11.4nF 93 H
RTD Option for 3051SF 5V 500 mA 0.63 W N/A N/A
Parameters FISCO
Voltage U
i
17.5 V
Current I
i
380 mA
Power P
i
5.32 W
Capacitance C
i
0
Inductance L
i
0
