Figure 3-7. Overview
Home
1 Overview
2 Configure
3 Service Tools
Overview
1 Device Status
2 Communications
3 Device Information
4 Analog Output
5 Variables
6 Calibration
7 Find Device
Communications
1 Variable Mapping
2 Communications Setting
3 Configure Burst Mode
Variable Mapping
1 Primary Variable
2 2nd Variable
3 3rd Variable
4 4th Variable
Variable Mapping
1 Polling Address
2 Loop Current Mode
Configure Burst Mode
1 Burst Mode
2 Burst Option
3 Burst Slot 0
4 Burst Slot 1
5 Burst Slot 2
6 Burst Slot 3
Device Information
1 General
2 Model Numbers
3 HART Revision Numbers
4 P-Hi Module Information
5 P-Lo Module Information
6 Alarm and Security
7 View Device Topology
General
1 Tag
2 Long Tag
3 Model
4 Date
5 Descriptor
6 Message
7 ERS Serial Number
8 Electronics Serial Number
Model Numbers
1 Model Number 1
2 Model Number 2
3 Model Number 3
4 Model Number 4
HART Revision Numbers
1 HART Universal
2 Field Device
3 Software
4 Hardware
P-Hi Module Information
1 Sensor Module Information
2 Flange Information
3 Remote Seal Information
Sensor Module Information
1 Sensor Module Serial Number
2 Type
3 Configuration
4 Sensor Range
5 Upper Limit
6 Lower Limit
7 Isolator Material
8 Fill Fluid
Flange Information
1 Process Connection
2 Connection Material
3 O-Ring Material
4 Drain / Vent Material
Remote Seal Information
1 Number of Seals
2 Remote Seal Type
3 Diaphragm Material
4 Fill Fluid
P-Lo Module Information
1 Sensor Module Information
2 Flange Information
3 Remote Seal Information
Sensor Module Information
1 Sensor Module Serial Number
2 Type
3 Configuration
4 Sensor Range
5 Upper Limit
6 Lower Limit
7 Isolator Material
8 Fill Fluid
Flange Information
1 Process Connection
2 Connection Material
3 O-Ring Material
4 Drain / Vent Material
Remote Seal Information
1 Number of Seals
2 Remote Seal Type
3 Diaphragm Material
4 Fill Fluid
Alarm and Security
1 Alarm Direction
2 High Alarm
3 High Saturation
4 Low Saturation
5 Low Alarm
6 Write Protect
To Next Page
