Section 11: Standard and Optional Machine
Features
132
Mugs With Handles
The drive wheels are each two piece assemblies with three o-rings when fully
assembled. Removing the front part of the drive wheels enables the user to
accommodate a wide variety of mugs with handles. Not all mugs with handles
require the front drive wheels to be removed.
The photo below shows a mug with a handle properly positioned on the rotary
attachment, with the
removable portion of the
drive wheel shown in the
foreground.
Fully assembled drive wheel.
Front drive wheel removed.
Loosen the two small thumb
screws on each wheel to remove
