Section 11: Standard and Optional Machine
Features
138
If placement of your artwork is critical, many users place a couple layers of masking
tape onto the area of the glass to be engraved and practice at high speed and low
power to mark only the tape.
Focus with the Rotary
Auto Focus – The auto focus feature works with the rotary attachment. Before using
auto focus, use the rotary attachments elevator to bring the top surface of the glass to
horizontal. With your glass properly positioned on the rotary attachment, lower the
table until the top surface of the glass is below the auto-focus plunger, then, auto
focus as normal.
Manual focus – With the glass horizontal and in proper position on the rotary
attachment, lower the table until the glass is below the auto focus plunger. Place the
manual focus gauge on the lens carriage and press the focus button. Spin the knob to
move the table up so that the manual focus gage just touches the glass. If the glass has
a taper, pick an intermediate point between the highest and lowest points being
engraved. Remove the gauge. Print the job with auto focus set to “No” in the print
driver.
Rotary Removal
1. Open the door.
2. Turn off the power to the Legend.
3. Depress the release tab on the rotary connector (front left inside corner) and
unplug the connector.
4. Remove the rotary attachment.
