Epson BrightLink 455Wi User Manual

Using the Projector on a Network 111
Using Wireless Security Options
The projector includes WEP and WPA data encryption security
options which you can enable for network projection.
Make sure the settings you select match the ones used by your
network; follow the directions from your network administrator.
See the following sections to enable security options on your
projector:
■ “Enabling WEP Encryption” below
■ “Enabling WPA Security” on page 113
You also need to enable security settings from EasyMP Network
Projection (see page 114).
Enabling WEP Encryption
1. Press Menu on the projector remote. Highlight Network and
then press
Enter.
2. Choose
Network Configuration and press Enter.
3. Highlight
Security, then press Enter. You see the following
screen:
4. Press
Enter to select Security, then select WEP and press Enter.
Press
Esc to return to the previous menu.
note
The authentication and
firewall features are only
effective when the access
point for the connection
destination supports the
same functions.

Epson BrightLink 455Wi Specifications

Projection

white light output	2500 lumens
color light output	2500 lumens
native resolution	1280 x 800 (WXGA)
throw ratio range (16:10)	0.37 – 0.50
throw ratio range (4:3)	0.44 – 0.59
throw ratio range (16:9)	0.37 – 0.50

Lamp Specifications

lamp type	E-TORL 230 W UHE
lamp life (ECO mode)	up to 3500 hours
lamp life (normal mode)	up to 2500 hours

Power

power supply voltage	100 – 240 V ±10%, 50/60 Hz
power consumption	363 W
network on standby power	10 W
network off standby power	0.3 W

Operating Environment

operating temperature	41 ˚ to 95 ˚F (5 ˚ to 35 ˚C)
fan noise (normal mode)	35 dB
fan noise (ECO mode)	28 dB

Weight and Dimensions

dimensions	14.5" x 19.0" x 6.1" (W x D x H)
weight with slide plate	14.1 lb
weight without slide plate	12.9 lb
