Epson BrightLink 455Wi User Manual

32 Connecting to Computers, USB Devices, and Other Equipment
Playing Sound from Video Equipment
For video equipment, use an RCA-style audio cable, which you can
purchase from an electronics store.
1. Connect the red and white plugs on one end of the cable to the
L
and
R Audio jacks on the projector.
2. Connect the red and white plugs on the other end to the
corresponding color-coded audio output jacks on your video
source.
note
If you are using a
component-to-VGA cable,
you will need to connect an
audio adapter to use the
Audio1 or Audio2 jack.
Connect to audio-out
ports for video equipment

Epson BrightLink 455Wi Specifications

Projection

white light output	2500 lumens
color light output	2500 lumens
native resolution	1280 x 800 (WXGA)
throw ratio range (16:10)	0.37 – 0.50
throw ratio range (4:3)	0.44 – 0.59
throw ratio range (16:9)	0.37 – 0.50

Lamp Specifications

lamp type	E-TORL 230 W UHE
lamp life (ECO mode)	up to 3500 hours
lamp life (normal mode)	up to 2500 hours

Power

power supply voltage	100 – 240 V ±10%, 50/60 Hz
power consumption	363 W
network on standby power	10 W
network off standby power	0.3 W

Operating Environment

operating temperature	41 ˚ to 95 ˚F (5 ˚ to 35 ˚C)
fan noise (normal mode)	35 dB
fan noise (ECO mode)	28 dB

Weight and Dimensions

dimensions	14.5" x 19.0" x 6.1" (W x D x H)
weight with slide plate	14.1 lb
weight without slide plate	12.9 lb
