Epson BrightLink 455Wi User Manual

82 Presenting With the Remote Control
■ If all the images in a folder do not fit on the Slideshow screen,
highlight
Next page at the bottom of the screen and press Enter
to display the next screen full of images. Select
Previous page at
the top of the screen to select the previous screen.
■ To exit the slideshow, press Esc, select Exit, and press Enter.
Selecting Slideshow Display Options
1. Highlight Option at the bottom left corner of the slideshow
screen and press
Enter. You see this screen:
2. Highlight the options you want to use, and press
Enter.
3. When you are finished, highlight
OK at the bottom of the screen
and press
Enter. (Highlight Cancel and press Enter to cancel.)
Option Available settings
Display
order
Name order displays files in name order
Date order displays files in date order
Sort order In Ascending sorts the files first to last
In Descending sorts the files last to first
Continuous
play
On displays a slideshow continuously
Off displays a slideshow one time through
Screen
switching
time
No does not switch file display automatically
1Sec. to 60Sec. displays files for the selected time
and switches them automatically

Epson BrightLink 455Wi Specifications

Projection

white light output	2500 lumens
color light output	2500 lumens
native resolution	1280 x 800 (WXGA)
throw ratio range (16:10)	0.37 – 0.50
throw ratio range (4:3)	0.44 – 0.59
throw ratio range (16:9)	0.37 – 0.50

Lamp Specifications

lamp type	E-TORL 230 W UHE
lamp life (ECO mode)	up to 3500 hours
lamp life (normal mode)	up to 2500 hours

Power

power supply voltage	100 – 240 V ±10%, 50/60 Hz
power consumption	363 W
network on standby power	10 W
network off standby power	0.3 W

Operating Environment

operating temperature	41 ˚ to 95 ˚F (5 ˚ to 35 ˚C)
fan noise (normal mode)	35 dB
fan noise (ECO mode)	28 dB

Weight and Dimensions

dimensions	14.5" x 19.0" x 6.1" (W x D x H)
weight with slide plate	14.1 lb
weight without slide plate	12.9 lb
