Epson BrightLink 455Wi User Manual

Presenting With the Remote Control 79
Then you can control your computer as follows:
■ Use the remote control’s Page Up or Page Down buttons to
move through presentation slides.
■ Use the arrow buttons to move the cursor on the screen.
■ Press the Enter button once to left-click, or twice to double-click.
Press the
Esc button to right-click.
■ To drag-and-drop, hold down the Enter button. Then use the
arrow buttons to drag the object. When it’s where you want it,
release the
Enter button.
Highlighting Your Presentation
You can display a pointer to call out important information on the
screen. If you want to customize the pointer tool, you can choose from
three alternative shapes.
Using the Pointer Tool
1. To activate the pointer tool, press the Pointer button on the
remote control. A pointer appears on the screen.
If you prefer to use a different style of pointer, see the instructions
in the next section.
2. Use the arrow buttons on the remote control to position the
pointer on the screen.
3. When you’re done using the pointer, press the
Pointer or Esc
button to clear the screen.
note
You can use the
Page Up/Page Down
feature with USB Display.
Pointer
button

Epson BrightLink 455Wi Specifications

Projection

white light output	2500 lumens
color light output	2500 lumens
native resolution	1280 x 800 (WXGA)
throw ratio range (16:10)	0.37 – 0.50
throw ratio range (4:3)	0.44 – 0.59
throw ratio range (16:9)	0.37 – 0.50

Lamp Specifications

lamp type	E-TORL 230 W UHE
lamp life (ECO mode)	up to 3500 hours
lamp life (normal mode)	up to 2500 hours

Power

power supply voltage	100 – 240 V ±10%, 50/60 Hz
power consumption	363 W
network on standby power	10 W
network off standby power	0.3 W

Operating Environment

operating temperature	41 ˚ to 95 ˚F (5 ˚ to 35 ˚C)
fan noise (normal mode)	35 dB
fan noise (ECO mode)	28 dB

Weight and Dimensions

dimensions	14.5" x 19.0" x 6.1" (W x D x H)
weight with slide plate	14.1 lb
weight without slide plate	12.9 lb
