Epson BrightLink 455Wi User Manual

84 Using the Projector Menus
Using the Menu System
You can use the remote control or the projector’s control panel to
access the menus and change settings. Follow these steps:
1. To display the menu screen, press the
Menu button on the
remote control or on the projector. You see a menu screen similar
to the one below:
The menus are listed on the left and the options available for the
highlighted menu are shown on the right.
2. Use the arrow buttons on the remote control or the projector to
scroll through the menu list. When you’ve highlighted the desired
menu, press the
Enter button to select it.
3. Once you’ve selected the menu, use the arrow buttons to scroll
through the list of options. (Some of the options may be grayed
out or unavailable, depending on the selected source.)
4. After highlighting the option you want to adjust, use the arrow
buttons to change the setting. In some cases, you may have to
press the
Enter button to view a sub-screen.
■ Press the left or right arrow button to adjust a slider bar.
■ To select from two or more settings, press the up or down
arrow button to highlight the setting and press
Enter.
Menu list
Options

Epson BrightLink 455Wi Specifications

Projection

white light output	2500 lumens
color light output	2500 lumens
native resolution	1280 x 800 (WXGA)
throw ratio range (16:10)	0.37 – 0.50
throw ratio range (4:3)	0.44 – 0.59
throw ratio range (16:9)	0.37 – 0.50

Lamp Specifications

lamp type	E-TORL 230 W UHE
lamp life (ECO mode)	up to 3500 hours
lamp life (normal mode)	up to 2500 hours

Power

power supply voltage	100 – 240 V ±10%, 50/60 Hz
power consumption	363 W
network on standby power	10 W
network off standby power	0.3 W

Operating Environment

operating temperature	41 ˚ to 95 ˚F (5 ˚ to 35 ˚C)
fan noise (normal mode)	35 dB
fan noise (ECO mode)	28 dB

Weight and Dimensions

dimensions	14.5" x 19.0" x 6.1" (W x D x H)
weight with slide plate	14.1 lb
weight without slide plate	12.9 lb
