Epson BrightLink 455Wi User Manual

Using the Interactive Pen 49
5. Continue until all of the circles are black.
After you have finished calibration, you can use either pen as a mouse
on the projection board or wall. With additional software, you can
also use the pen to write or draw on the projected image. See the next
section for more information.
Using the Pen
The Easy Interactive Driver allows you to use the pen as a mouse. If
you installed interactive whiteboard software you can also use the pen
to write or draw on the projected image.
Press the button on the pen to test the battery. If the indicator light is
green, the battery has enough power.
Follow these tips to use the pen as a mouse:
■ For best performance, hold the pen at an angle, rather than
perpendicular to the board.
■ To left-click, tap on the board.
■ To double-click, tap twice.
Battery indicator
light
Button

Epson BrightLink 455Wi Specifications

Projection

white light output	2500 lumens
color light output	2500 lumens
native resolution	1280 x 800 (WXGA)
throw ratio range (16:10)	0.37 – 0.50
throw ratio range (4:3)	0.44 – 0.59
throw ratio range (16:9)	0.37 – 0.50

Lamp Specifications

lamp type	E-TORL 230 W UHE
lamp life (ECO mode)	up to 3500 hours
lamp life (normal mode)	up to 2500 hours

Power

power supply voltage	100 – 240 V ±10%, 50/60 Hz
power consumption	363 W
network on standby power	10 W
network off standby power	0.3 W

Operating Environment

operating temperature	41 ˚ to 95 ˚F (5 ˚ to 35 ˚C)
fan noise (normal mode)	35 dB
fan noise (ECO mode)	28 dB

Weight and Dimensions

dimensions	14.5" x 19.0" x 6.1" (W x D x H)
weight with slide plate	14.1 lb
weight without slide plate	12.9 lb
