Basic Operations
33
Adjusting the projection size (zoom adjustment)
Press the buttons to adjust the size of the projected screen.
Adjusting the position of the projected image (lens shift)
If the projector cannot be setup in front of the screen, you can adjust the position of the image by using lens
shift.
Use the buttons to adjust the po-
sition of the image.
c
Hold down the but-
tons to return to the center position.
You can move the image within the range indicated by
the dotted line in the figure on the right.
Caution
When transporting the projector, set the vertical and horizontal lens positions to the center. If you transport
the projector when the lens is shifted up, down, left, or right, the lens shift mechanism could be damaged.
c
When you cannot install the projector directly in front of the screen, it is recommended that you use
lens shift to adjust the projection position. If you cannot adjust using lens shift, try using keystone
correction.
