Chapter 2 Description of Functions
49
[ 1 ] Read the function code setting values from the inverter
When you want to update the function code setting values read from the inverter
Click [Read] button to open the following dialog. Click [OK] to read the function code setting
values from the inverter again.
[ 2 ] Write the function codes from the loader to the inverter
To write the function codes to the inverter, use [Write] button displayed at the lower bottom of the
List Edit window appearing when editing function codes.
・Editing function code data (blue part) only
This function writes to the inverter only the setting values of the function codes that are
edited by the loader and have not been written to the inverter yet (displayed in blue).
・Registered user definition function code data only
This function writes only the setting values of the function codes registered to the user
definition on the List Edit window.
・Different from the factory function code data (with *) only
This function writes the setting values to the inverter only when those of function codes are
different from the factory-set values (excluding communication codes).
・All function code data
This function writes all the function code setting values in the table
(excluding
communication codes).
To Next Page
