Stapler Faults
599
Problem Solving
15
Staple Jams in Staple Cartridge (For Finisher-C1 or Finisher-C1
with Booklet Maker)
This section describes how to clear staple jam occurred in the staple cartridge of the Finisher-
C1 (optional) and the Finisher-C1 with Booklet Maker (optional).
This section explains the procedures to remove the jammed staples in the C1-Finisher with
Booklet Maker, as an example. You can apply the same procedures to the Finisher-C1.
1 Make sure that the machine is not operating,
and open the finisher front cover.
2 Grasp the handle R1 of the staple cartridge
holder, and pull out the holder to the right,
towards you.
3 Take out the staple cartridge.
Note • The staple cartridge is firmly inserted. A slight
force is required to pull the cartridge out of
the finisher.
4 After you take out the staple cartridge, check
inside of the finisher for any remaining staples.
To Next Page
