5-1
5. VIDEO PLOTTER OPERATION
The video plotter has the following functions:
• Enter waypoints (up to 98) and marks.
• Creates and displays radar maps.
• Own ship track plotting
• Able to save marks and tracks on removable SD-card.
5.1 Orientation Modes
Six orientation modes are available:
[HEAD UP RM], [STAB HEAD UP RM],[STERN UP RM], [COURSE UP RM], [NORTH
UP RM], [NORTH UP TM] (True Motion).
Note 1: The [STERN UP RM] orientation mode is only available it has been set to [ON]
in [STERN UP RM] in the [INITIAL SETTING] o [OPERATION] menu.
Note 2: The screen may flash when the heading is changed more than one degree in
the [HEAD UP RM] or [STAB HEAD UP RM] mode.
Automatic resetting of own ship mark in true motion mode
In the true motion mode, the own ship mark is automatically returned stern-ward 75%
from the screen center when it reaches a location 50% of the display radius.
To select an orientation mode, see "How to select an presentation mode" on page 1-
32.
