1. OPERATIONAL OVERVIEW
1-65
1.44 How to Display and Set Up Navigational Data
Wind, depth, ocean current, water temperature, date and time and waypoint data can
be displayed on this radar, however appropriate sensors are required.
1.44.1 How to set up the navigational data
1. Open the [MAIN MENU].
2. Select [INFORMATION BOX], then push the ADJUST knob.
3. Select [SET NAV DATA], then push the ADJUST knob.
4. Referring to the table below, select the appropriate menu item, then push the AD-
JUST knob.
5. Referring to the available options listed in the table above, select the appropriate
setting, then push the ADJUST knob.
6. Close the menu.
1.44.2 How to display navigational data
1. Open the [MAIN MENU].
2. Select [INFORMATION BOX], then push the ADJUST knob.
3. Select [NAV DATA], then push the ADJUST knob.
4. Select [ON] to display navigational data, [OFF] to hide navigational data, then
push the ADJUST knob.
5. Close the menu.
Menu item Available settings
DEPTH [OFF], [ON] (m, ft)
DEPTH GRAPH SCALE [10], [20], [50], [100], [200], [500] (m)
DEPTH MARK [000] to [500] (m)
CURRENT [OFF], [ON]
WIND [OFF], [ON] (kn, m/s)
WIND STAB [APPARENT], [NORTH], [THEORETICAL]
TEMPERATURE [OFF], [ON] (°C, °F)
WPT DATA [OFF], [REL], [TRUE]
