Furuno FAR-1518 User Manual

5. VIDEO PLOTTER OPERATION
5-7
How to enable the arrival alert
Arrival WPT is a function to alert when own ship nears a waypoint by a preset
distance. Alert range is shown to your radar with orange hashed line as follow:
Note: Set [NAVLINE DATASOURCE] on [NAV LINE•WPT] to [EXT DATA] in ad-
vance.
1) Open the [MAIN MENU].
2) Select [ALERT], then push the ADJUST knob.
3) Select [ARRIVAL WPT], then push the ADJUST knob.
4) Select [ON] to enable [ARRIVAL WPT].
5) Rotate ADJUST knob to select a digit (0.00 NM~9.99 NM), then push the ADJUST
knob.
6) Close the menu.
5.5.2 How to erase waypoints
1. Open the [MAIN MENU].
2. Select [NAVLINE•WPT], then push the ADJUST knob.
3. Select [WPT SET], then push the ADJUST knob.
4. Select [WPT NO. SELECT], then push the ADJUST knob.
5. Select [CLEAR DATA], then push the ADJUST knob.
6. Select [YES] or [NO] as appropriate, then push the ADJUST knob.
7. Close the menu.
5.5.3 How to display the waypoint list
1. Open the [MAIN MENU].
2. Select [NAVLINE•WPT], then push the ADJUST knob.
3. Select [WPT LIST], then push the ADJUST knob.
4. Close the menu.
5.5.4 How to show/hide the waypoint name/number
1. Open the [MAIN MENU].
2. Select [NAVLINE•WPT], then push the ADJUST knob.
3. Select [DISP WPT NO.] or [DISP WPT NAME] as appropriate, then push the AD-
JUST knob.
4. Select [YES] to show the waypoint name/number, or [NO] to hide the waypoint
name/number, then push the ADJUST knob.
5. Close the menu.
Own ship
position
Alert Range
Waypoint
: Alert Range
