1.9 How to Set Up Function Keys
Some menu functions and menus can be assigned to a function key. This allows one-
touch access to the assigned function or menu.
To activate an assigned function, press the corresponding function key (F1, F2 or F3).
The function keys are preset with the following functions:
F1: A/C RAIN, F2: A/C SEA, F3: ACE (Gain).
You can change the function assigned to each key using the following procedure.
1. Open the [MAIN MENU].
2. Select [INITIAL SETTING], then push the ADJUST knob.
3. Select [FUNCTION KEY], then push the ADJUST knob.
4. Select [F1], [F2] or [F3] as appropriate, then push the ADJUST knob.
5. Referring to the table of available functions below, select a function category, then
push the ADJUST knob.
*: Non-IMO radars only.
6. Select the appropriate function to assign, then push the ADJUST knob.
7. Close the menu. Repeat the procedure as necessary to set up other function keys.
Function
category
Available function
ECHO CUSTOM MENU, IR, ES, EAV, NOISE REJ, ANT SELECT, PULSE LENGTH,
AUTO-SEA, AUTO-RAIN, TUNE SELECT, 2ND ECHO REJ, PM, SART, ECHO
TRAIL, TRAIL T/R, WIPER, ACE, ACE HIGH SENSITIVITY
STD KEY ALERT ACK, STBY TX, EBL OFFSET, PRESENTATION MODE, CU-TM RE-
SET, VECTOR TIME, VECTOR MODE, TARGET LIST, BRILL, MARK-CUR-
SOR, MARK-OS, MENU, RANGE UP, RANGE DOWN, ACQ, TARGET DATA,
TARGET CANCEL
TT•AIS TT-DISP, AIS-DISP, PAST POSN INTERVAL, REF MARK, CPA LIMIT, CPA,
TCPA, AZ1, AZ2, AIS SCALED SYMBOL
DELETE DATA MARK DELETE, MARK ALL DELETE, OWN TRACK DELETE, OWN TRACK
ALL DELETE
OPERATION ECHO AREA*, ECHO COLOR, RING(ON/OFF), ZOOM, MOB, ALARM1,
ALARM2, TLL, MAP ALIGN
To Next Page
