5. VIDEO PLOTTER OPERATION
5-2
5.2 Radar Map
A radar map is a combination of map lines and symbols whereby the user can define
and input the navigation data, route planning and monitoring data. The radar map can
contain 5,000 points of data. Inscribed marks are retained when the power is turned
off.
The radar map is reference to the WGS-84 datum and is displayed only when there is
valid position data input. The radar map does not affect any radar functions.
5.2.1 How to show/hide the radar map
Select the [MAP] indication in the [RADAR CONTROL
BOX] at the left-side of the screen, then press the left
button to display or hide the radar map.
5.2.2 Radar map marks
To inscribe/remove marks or change mark colors on the radar map, see "How to Use
Marks" on page 1-57. The following mark icons are available.
IMO type*
2
Non-IMO type*
1
Mark Red Buoy
Danger Highlight Green Buoy
Buoy Red Buoy
Buoy
Green
Buoy
Buoy Red Buoy
Buoy Green Buoy
Buoy
Red Buoy
Danger Highlight
Green Buoy
Mark Purple Danger Highlight
Mark
Purple
Danger Highlight
Mark Orange Mark
Mark Orange Mark
Mark Orange Mark
Mark Purple Navline (map)
Mark White Coastline
Nav Line (map) Gray Contour Line
Coastline Purple Danger Highlight
Contour Purple (cable) Danger Highlight
Prohibited Area Orange Mark
(cable) Danger Highlight Orange Mark
(w/line) Buoy
(w/line) Mark
(w/line) Mark
(w/line) Mark
Item on
MARK menu
Item on
MARK menu
*
1
: Colors for non-IMO marks may be
set by the user.
*
2
: Colors for IMO marks are fixed as
indicated.
