Furuno FAR-1518 User Manual

FURUNO FAR-1513/1523 (-BB)
SP - 1 E3638S01E-M
SPECIFICATIONS OF MARINE RADAR
FAR-1513/1523 (-BB)
1 ANTENNA UNIT
1.1 Antenna type Slotted waveguide array
1.2 Radiator length 4 ft (XN12A), 6 ft (XN13A)
1.3 Horizontal beamwidth 1.9° (XN12A), 1.35° (XN13A)
1.4 Vertical beamwidth 20°
1.5 Sidelobe attenuation
XN12A -24 dB (within ±20° of main-lobe)
XN13A -28 dB (within ±20° of main-lobe)
1.6 Polarization Horizontal
1.7 Rotation 24 rpm (RSB-0070), 48 rpm (RSB-0073)
2 RF TRANSCEIVER
2.1 Frequency 9410 MHz ±30 MHz, P0N
2.2 Output power
FAR-1513 (-BB) 12 kW
FAR-1523 (-BB) 25 kW
2.3 Minimum range 25 m
2.4 Range discrimination 25 m
2.5 Range accuracy 1 % of range in use or 10 m whichever is the greater
2.6 Bearing accuracy ±1°
2.7 Range, Pulselength and Pulse Repetition Rate
PRR
(Hz approx.)
Range scale (NM)
0.125 0.25 0.5 0.75 1 1.5 2 3 4 6 8 12 16 24 32 48 96
2100 S
1200 M
600* L
*: 500 Hz on 96 NM ranges
2.8 IF frequency 60 MHz
3 PROCESSOR UNIT
3.1 Range scales and ring interval
Scale (NM) 0.125 0.25 0.5 0.75 1 1.5 2 3 4 6 8 12 16 24 32 48 96
RI (NM) 0.025 0.05 0.1 0.25 0.25 0.25 0.5 0.5 1 1 2 2 4 4 8 8 16
Number of rings 5 5 5 3 4 6 4 6 4 6 4 6 4 6 4 6 6
3.2 Echo tones 32 levels
3.3 Warm-up time 90 s approx. (FAR-1513), 3 minutes approx. (FAR-1523)
3.4 Presentation mode Head-up, STAB Head-up, North-up (TM/RM), Course-up, Stern-up
3.5 Marks Cursor, Radar ring, Heading mark, North mark, Bearing line,
Vector, Map mark, Zoom, VRM, EBL, Acquisition zone
3.6 Target tracking (TT) Auto or manual acquisition: 50 targets in 0.2-32 NM
Tracking: 5/10 pts on all target
Time of vector: 30 s to 60 minutes
3.7 AIS Display capacity: 300 targets, Tracking: 5/10 pts on all target
Time of vector: 30 s to 60 minutes
