1-2
1.2 Boards & Major Components
DISPLAY UNIT
Board Name Type
SPU Board 03P9253
PTU (PWR) Board AC : 03P9245
FILTER Board AC : LF-210
PANEL Board (in control head) 03P9255
PAL Board (in control head) 03P9254
PAR Board (in control head) 03P9256
INT Board 03P9252
Mother Board 03P9251
ARP Board (Optional ARP-26) 18P9002 B
RP Board (Optional RP-26) 14P0298
Card I/F Board (Optional RP-26) 14P0299
PDM Board PDM-9025
Gyro Board (Optional GC-8) 64P1106 A
PM Board (Optional PM-30/50) 03P9225
RGB Buffer Board (Optional) 03P9229
CRT Unit CDT2136B
Power Supply Unit (PSU-001)
Board Name
Type
TX-HV POWER SUPPLY (1) 03P6810
TX-HV POWER SUPPLY (2) 03P6680
POWER SUPPLY PCB 03P6667
INT PCB 03P9003
