Furuno FR-2155 User Manual

2-25
2.24 INPUT/OUTPUT Data on INT Board (03P9252)
Port Name
I; input,
O: output
Signal Name Signal Format
Equipment
Connectable
Remarks
J442 (O)
J443 (O)
Slave display
TRUE-TRIG, VIDEO
,TRU-HD, BP
Radars having
slave func-tion
Timing between TRU-TRIG and
VIDEO adjusted, HD adjusted,
BP:360 pulse/rotation.
J444 (O) External ARPA
ARPA-TRIG, VIDEO
,ARPA-HD, BP
Other make’s
ARPA
Timing between ARPA-TRIG
and VIDEO adjusted on ARPA,
HD adjusted BP:360 pulse/
rotation.
J446 (I) HDG
AD10 format,
25 msec
GC-1/2/6/7/8
AD-10/10S/100
Generating HM, NU/TM modes,
True EBL, True vector(E-PLOT),
signal processing 1/2/3, True
echo trail, ARP-26.
J448 (I) Speed
Contact closure
(200 or 400 pulses)
DS-30/70
CI-30/60/80
GP-500
GP-500MK2
Ship’s speed data, TM mode,
True vector (E-PLOT), signal
processing 1/2/3, True echo
trail, ARP-26.
J449 (O) Remote display
R, G, B, H-SYNC,
V-SYNC
Monitor,Printer
Buffer Board (03P9229)
required
J450 (I/O) Nav data
NMEA0183 V2.0
(Current Loop)
I:Navaid;
GP-70MK2
GP-80
GP-500MK2
O:PC
I:L/L, Speed/Course, L/L of
+cursor, Dated & Time, Current ,
Depth, etc.
O:RSD,OSD
IEC 61162
(RS-422 Level)
J452 (O) External buzzer
+5 V
Buzzer
150 mA max.
J453 (I) Analog Analog data Not
used
J454 (O) ARPA data
NMEA0183, V2.0
(RS-422 Level)
GD-551, PC
$RATTM (ARPA Tracking Target
Data)
J455 (I) INS data
NMEA0183, V2.0
(Current Loop or
RS-422 Level)
INS
Receiving VHW/VBW from DS-30/
50 etc., HDT, HDM and HDG.
J456 (I/O) RS-232C RS-232C level PC
For program update
J457 (I/O) RJ-7 RJ-7 Input/Output RJ-7
J458 (I) RJ-7
TRUE-TRIG, VIDEO
,TRU-HD, BP
RJ-7 or
Radar having
output for
slave display
Timing between TRU-TRIG and
VIDEO adjusted, HD adjusted,
BP:360 pulse/rotation.
J463 (O) I/F Power Supply +5 V, -12 V, +12 V
Additional
Circuit e.g.
Buffer Board
+5 V: 100 mA max.
+12 V: 200 mA max.
-12 V: 200 mA max.
