3-11
Location of Parts on GYRO Board (64P1106)
Test points and Ratings
TP No. Signal Rating Condition
TP1 +5 V 5.19 to 5.21 VDC, adjusted by R42
JP1
F1
F2
F3
F4
CR21
JP7
JP3
JP5
JP2
JP4
R42
CR22
TP1
JP8
BT1
