Furuno FR-2155 - Scanner Unit Adjustment Procedures

3-19
3.2 Adjustment (Scanner Unit)
Location of Parts on Scanner Unit (RSB-0049/0050)
Scanner Unit, side view, cover removed
Scanner Unit, stern side, cover removed
Scanner Unit, stern side, cover and RF Unit removed
RF Unit (RTR-030)
R812
R811
Scanner Motor
Reed switch
Bearing SIG GEN Board
(MP-3795)
STB-3
STB-1
STB-2
ANT SW
De-icer sensor
Clamping gland
