3-18
Location of Parts on Power Supply Unit (PSU-004)
PTB-12
PTB-14
PTB-11
PTB-13
Fuse
F1
(
10A
)
Fuse
F2 (10A)
Fuse
F3 (2A)
THERMAL RELAY
K2
RELAY (Under Side)
K3
RELAY Board
03P9146
RELAY
K1
