4.2 Jumper Settings

Board Specification Jumper Settings Remarks

03P9245A

(PTU Board, AC)

100 VAC, 24 rpm

JP1: Yes

JP2: Yes

JP3: Yes

JP4: No

JP91: No

JP92: No

R98:4.7 k ohms

03P9245D

(PTU Board, AC)

220 VAC, 24 rpm

JP1: No

JP2: No

JP3: No

JP4: Yes

JP91: No

JP92: No

R98:4.7 k ohms

INS RX (C) fromat J468: J1-J2

INS RX (H) fromat J469: J1-J2

J1-J2: Current loop

J3-J4: RS-422

03P9252

(INT Board)

ANALOG input level

J471: J1-J2

J1-J2:L, J3-J4:M, J5-J6:H

Battery connection

JP1: Yes

03P9253

(RP Board)

not used JP2: No
