3-15
Location of Parts on INT Board (03P9003)
Test point and Ratings
TP No. Signal Rating Condition
PTB-2 #7(+)
#8(-)
HEATER 8.2 to 8.8 V, adjusted by R813
ST-BY, 0.25NM
PTB-2
R813
