GE HEALTHCARE
D
IRECTION 5141177-100, REVISION 14 BRIGHTSPEED ELITE, EDGE, EXCEL: PRE-INSTALLATION
Chapter 6 - Floor Loading and Weights Page 103
6 – Floor Loading
Chapter 6
Floor Loading and Weights
Section 1.0
Floor Loading
The BrightSpeed system has a total floor load of approximately 2880 kg (6340 lbs). About 2310 kg
(5088 lbs), including patient (205 kg (450 lbs)), is concentrated in the table-gantry assembly.
Table 6-1 lists CT components with weight, size, floor loading and normal mounting requirements.
ITEM NET WEIGHT
LB(KG)
OVERALL
W X D
INCH (MM)
WEIGHT/AREA
LB/SQ. FT.
(KG/M
2
)
LOAD PATTERN
IN. (MM)
NORMAL METHOD OF
MOUNTING IN. (MM)
(GE SUPPLIED)
1
Gantry (w/
covers)
~3899
(~1770)
81 x 40.1
(2057 x 1018)
263 (1286) Rectangular base plate 27.6
X 77.4 (700 X 1966) with four
round pads, each 2.5 (63.5)
in contact with floor.
Individual pad loadings are:
910 lb, 960 lb, 1040 lb, and
1090 lb (see Figure ).
Hilti Kwik-Bolt II 1/2in (12.7mm)
diameter by 8in (203mm) long per P/N
2106573 at four leveling pads into
concrete floor.
Dollies (each) 250 (114)
Top Cover (each) 15.4 (7)
Side Cover (each) 11 (5)
Front Cover 92.5 (42)
Rear Cover 92.5 (42)
Patient Table 1201 (545)
Includes 450
(205) Patient
24.3 x 94
(616 x 2387)
175 (852) Rectangular base 17 X 57.5
(432 X 1460) with five round
pads, each 2.5 (63.5) in
contact with floor. Worst-
case cantilever pull on any
bolt is 1235 lb (561 kg).
Hilti Kwik-Bolt II 1/2in (12.7mm)
diameter by 8in (203mm) long per P/N
2106573 at three leveling pads into
concrete floor.
Dolly 215 (98)
Patient Table:GT
1700V w/227kg
patient
980 (445) /
1481 (672)
25.6 x 93.3
(650 x 2370)
493 (2408) For round 63.5mm pads.
Max Anchor Load is 1363lbs
(6061N).
Hilti Kwik-Bolt II 1/2in (12.7 mm)
diameter by 8in (203mm) long per P/N
2106573 at the leveling pads into
concrete floor.
Foot Switch 73 (33) - - - -
Power Distribution
Unit
~770
(~350)
28 x 22
(700 x 550)
185 (909) Four Casters support area of
28 X 22 (711 X 559).
Casters are for positioning and service.
Set on floor. May be anchored to floor
using angle brackets
2
in seismic
zones.
Console w/
single-piece
desktop & w/o
monitors
Elite:
430 (195)
Edge/Excel:
397 (180)
48.8 x 48.6
(1240 x 1235)
Eilte: 140 (681)
Edge/Excel:
134 (652)
Four Casters or Leveling
Feet support area of 46 X 19
(1168 X 483).
Casters are for positioning. Set on
floor. Console may be anchored to
floor using angle brackets
2
Notes:
1.) Use the GE Supplied mounting hardware ONLY IF APPROVED by qualified personnel.
[See statements in 8.1 - Table and Gantry Mounting Requirements, on page 84.]
2.) Seismic angle brackets are included and shipped with the PDU..
Table 6-1 BrightSpeed System Floor Loading
