GE HEALTHCARE
D
IRECTION 5141177-100, REVISION 14 BRIGHTSPEED ELITE, EDGE, EXCEL: PRE-INSTALLATION
Page 120 Section 5.0 - Table Considerations
Section 5.0
Table Considerations
5.1 HP-Power Table
The table is shipped with 2 crates. The mainbody of table is put in crate without dollies. Bottom
Cover and accessaries are shipped in another crate.
For the table shipping dimensions, refer to Table 7-2.
Table 7-2 H-Power Table Shipping Dimensions
5.2 GT1700 Table
The table is shipped without side covers installed. Covers are shipped in separate boxes. The table
is mounted with two dollies. For the table dimensions with dollies, refer to Table 7-3
Section 6.0
Console Considerations
LCGOC/GOC4/AIO Console:
The console is shipped without the keyboard table installed. The keyboard table is shipped with the
console. See Figure 7-2.
The dimensions of the console alone (as shipped) are 1170mm ( 46 in. ) deep, 1340mm (53 in. )
wide, and 1150mm ( 45 in. ) high.
LENGTH WIDTH HEIGHT
MM IN MM IN MM IN
2620 103 900 35 1300 51
1700 67 770 30 750 30
LENGTH WIDTH HEIGHT WEIGHT
MM IN MM IN MM IN KG LB
GT1700V 2489 98 762 30 1143 45 576 1270
Table 7-3 GT1700 Table Dimensions with dollies
