GE HEALTHCARE
D
IRECTION 5141177-100, REVISION 14 BRIGHTSPEED ELITE, EDGE, EXCEL: PRE-INSTALLATION
Chapter 9 - Interconnection Data Page 137
9 – Interconnects
3.2 GEMS Supplied (Freedom Workspace Table Extended Cables Kit)
Extended Cables Kit (5160577) is used for FWS:
Note: Freedom Workspace Table is only used for BrightSpeed and BrightSpeed Select series Systems.
Table 9-6 TIO Console Extended Cables
DESCRIPTION QUANTITY CONNECT TO PART NUMBER LENGTH
IN MM
DVI-A HD15 Video Cable 1 Monitor 5160573 181.10+/-3.94 4600+/-100
DVI-A HD15 Video Cable 1 Monitor 5160573-2 181.10+/-3.94 4600+/-100
USB Extension Cable 1 Trackball 5160574 118.11+/-3.94 3000+/-100
PS_2 Extension Cable 1 Keyboard 5160575 118.11+/-3.94 3000+/-100
PS_2 Extension Cable 1 Mouse 5160575-2 118.11+/-3.94 3000+/-100
SCIM CABLE 1 SCIM 5160576 251.97+/-3.94 6400+/-100
Power Code 2 Monitor 5162253 216.54+/-3.94 5500+/-100
Table 9-5 Extended Cables
PART # DESCRIPTION CONNECT TO QUANTITY LENGTH
MM INCHES
5160575-2 PS_2 EXTENSION CABLE Mouse
1
3000+/-100 118.11+/-3.94
5160574 USB_EXTENSION CABLE Keyboard
1
3000+/-100 118.11+/-3.94
5332107-2 CABLE, DVI to D-SUB VIDEO
CABLE
Monitor
2
3000+/-20 118.11+/-0.79
5332093-2 CABLE, SCIM HD50-HD50 SCIM
1
3250+/-25 127.95+/-0.98
5315370 CABLE, USB TYPE A-B PMT Tower
3
2000 78.74
5332100-2 Power Cord 3.5meter PMT Tower/LCD Monitors
4
3500+/-30 137.80+/-1.18
To Next Page
