GE HEALTHCARE
D
IRECTION 5141177-100, REVISION 14 BRIGHTSPEED ELITE, EDGE, EXCEL: PRE-INSTALLATION
Chapter 6 - Floor Loading and Weights Page 105
6 – Floor Loading
Section 2.0
Mounting Data, Including Seismic
WARNING POTENTIAL FOR PATIENT INJURY.
IMPROPERLY SECURED TABLE MAY TIP, DISLODGING PATIENT.
PROPER ANCHORING IS KEY TO MAINTAINING PATIENT SAFETY DURING
SYSTEM OPERATION.
The following pages show center-of-gravity information for system components:
Gantry: Figure 6-2
•Table: Figure 6-4, Figure 6-5
Power Distribution Unit: Figure 6-6
Operator's Console/Computer: Figure 6-8, Figure 6-9,
Freedom Workspace Table. Figure 4-15, Figure 4-16, Figure 4-17, Figure 4-18
Floor mounting hole locations for components that don't have templates are also in this section.
Customer is responsible for seismic mounting. Refer to all applicable codes in your area.
GE provided floor anchors (Figure 6-1) are designed to be used ONLY on concrete floors that meet
the concrete floor requirement. Supplied floor anchors must be installed by a trained contractor, and
shall be set to a minimum depth of 3 inches at each anchor point. Any anchors having more than 1
inch of thread showing above the nut, when torqued to 55 ft.-lbs, shall have a second anchor
installed in the closest adjacent hole. the second anchor shall be installed to the standard depth and
torque specifications.
Note: If the Installers cannot set all for anchors for the GT1700V table, the installer must inform the
customer that the minimum anchoring cannot be met, and structural engineering contractor is
strongly recommended to determine the anchoring method and certify that their anchoring meets
the stated GE minimum load requirement and torque specifications.
Note: All other anchoring methods on floor types other than the concrete minimum must be determined
at the customer’s expense by a structural engineering contractor, and anchoring method must be
certified to meet the stated GE minimum load requirement and torque specification.
Note: If installing the GE BS scanner on a floor type other than a 4 inch concrete floor, all structural
specifications in this document must be reviewed and met.
MOUNTING REQUIREMENTS GANTRY TABLE
Minimum Floor Thickness: 102 mm (4 in. ) 102 mm (4 in. )
Recommended Drilling Depth: 95 mm (3.75 in. ) 95 mm (3.75 in. )
Average Anchor Embedment: 89 mm (3.5 in. ) 89 mm (3.5 in. )
Minimum Anchor Embedment: 76 mm (3 in. ) 76 mm (3 in. )
Available Alternate Anchor Locations: Yes Yes
Shipped Anchor Size: 203 mm (8 in.) 203 mm (8 in.)
Alternate Anchoring Methods: Yes (see notes, below) Yes (see notes, below)
FLoor Levelness Requirement: 6 mm (1/4 in.) over 3 m
(10 ft.)
6 mm (1/4 in.) over 3 m (10
ft.)
Table 6-2 Gantry and Table Mounting Requirements
