Page 44 Chapter 2 - Pre-Installation Overview
Section 4.0
Broad-band
For information on Broad-band requirements, refer to Chapter 4, Section 9.0, on page 87.
Section 5.0
Phone Line (for optional modem)
Two phone lines must be installed at or near the console and be operational prior to installation.
• 1-Analog line (for modem use)
• 1-Voice line
Section 6.0
Review
The BrightSpeed Series systems use adjustable leveling pads to support the gantry and table. The
gantry has four (4) primary leveling pads. The table has five (5) pads used for leveling it.
Using the GE print to establish the room layout, make sure all the operating and service clearances
shown on the print are observed. Using the template (P/N 5160024/5341997) shipped with the
system, locate the anchor holes. Make sure they clear structural interferences in the floor.
Clean the area. Free the mounting surface of any material that may interfere with the positioning
and leveling of the system.
1.) Lay out the 2 floor templates.
2.) Start with the Gantry template—align per the GE print.
3.) Place the table template over the top of the Gantry template. Align the scan and table center-
lines and secure the templates to the floor. Make sure there are no potential clearance issues.
4.) Check the level of the floor (See Figure 2-1) across the templates. This should be measured
on the template over the table/gantry area, as shown in Figure 2-1 below.
FLOOR LEVELNESS SPECIFICATION: 6 mm (1/4 in.) over 3 m (10 ft.)
Note: Tiles (or other resilient flooring) around all holes will be cut during the installation process.
