GE HEALTHCARE
D
IRECTION 5141177-100, REVISION 14 BRIGHTSPEED ELITE, EDGE, EXCEL: PRE-INSTALLATION
Page 148 Section 3.0 - Interconnect Runs, Wiring and Cables
3.5 Contractor (Customer) Supplied
CUSTOMER
INSTALLED WIRING
DESCRIPTION CABLES SUPPLIED PLUG PULLING
DIMENSIONS
WIRE & CABLE
PIGTAILS FT. (M.)
QTY SIZE AWG
(MM
2
)
PART NO LENGTH
FT. (M.)
DIA.
IN (MM)
FROM TO FROM TO
RUN NO. 1 FROM PRIMARY POWER SOURCE TO FACILITY DISCONNECT (POWER SOURCE - A1)
Maximum Run Length *
3 * POWER 3 (1) 3(1)
1 1/0 (50) GROUND 3 (1) 3 (1)
RUN NO. 2 FROM FACILITY DISCONNECT TO POWER MODULE (A1 - PM) MAXIMUM RUN LENGTH *
3* POWER 3 (1) 3(1)
1 1/0 (50) GROUND 3 (1) 3 (1)
1 * NEUTRAL (Not Required) 3 (1) 3 (1)
RUN N0. 3 FROM FACILITY DISCONNECT TO SYSTEM EMERGENCY OFF (A1 - SEO)
214 (2) POWER 6 (2) 6 (2)
1 14 (2) GROUND 6 (2) 6 (2)
RUN NO. 4 POWER MODULE TO WARNING LIGHT CONTROL (PM - WL)
2 14 (2) WARNING LIGHT 24 VOLT
CONTROL A3J2-1,2,3,4
RUN NO. 5 POWER MODULE TO SCAN ROOM DOOR INTERLOCK (PM - DOOR SWITCH)
2 14 (2) SCAN ROOM DOOR INTER
LOCK A3J6-1,2
* REFER TO Table 8-3 on page 131 FOR AWG (MM2) WIRE SIZES.
Table 9-12 Runs 1, 2, 3, 4 and 5 Connections
