GE Multilin L30 Line Current Differential System 5-233
5 SETTINGS 5.7 CONTROL ELEMENTS
5
5.7.10 MONITORING ELEMENTS
a) MAIN MENU
PATH: SETTINGS  CONTROL ELEMENTS  MONITORING ELEMENTS
b) BREAKER ARCING CURRENT
PATH: SETTINGS  CONTROL ELEMENTS  MONITORING ELEMENTS  BREAKER 1(2) ARCING CURRENT
 MONITORING
 ELEMENTS
 BREAKER 1
 ARCING CURRENT
See page 5–233.
MESSAGE
 BREAKER 2
 ARCING CURRENT
See page 5–233.
MESSAGE
 CT FAILURE 1
 DETECTOR
See page 5–236.
MESSAGE
 CT FAILURE 2
 DETECTOR
See page 5–236.
MESSAGE
 VT FUSE FAILURE 1

See page 5–237.
MESSAGE
 VT FUSE FAILURE 2

See page 5–237.
MESSAGE
 BROKEN CONDUCTOR 1

See page 5–239.
MESSAGE
 BROKEN CONDUCTOR 2

See page 5–239.
MESSAGE
 THERMAL OVERLOAD
 PROTECTION
See page 5–241.
 BREAKER 1
 ARCING CURRENT
BKR 1 ARC AMP
FUNCTION: Disabled
Range: Disabled, Enabled
MESSAGE
BKR 1 ARC AMP
SOURCE: SRC 1
Range: SRC 1, SRC 2
MESSAGE
BKR 1 ARC AMP INT-A:
Off
Range: FlexLogic operand
MESSAGE
BKR 1 ARC AMP INT-B:
Off
Range: FlexLogic operand
MESSAGE
BKR 1 ARC AMP INT-C:
Off
Range: FlexLogic operand
MESSAGE
BKR 1 ARC AMP
DELAY: 0.000 s
Range: 0.000 to 65.535 s in steps of 0.001
MESSAGE
BKR 1 ARC AMP LIMIT:
1000 kA2-cyc
Range: 0 to 50000 kA
2
-cycle in steps of 1
MESSAGE
BKR 1 ARC AMP BLOCK:
Off
Range: FlexLogic operand
MESSAGE
BKR 1 ARC AMP
TARGET: Self-reset
Range: Self-reset, Latched, Disabled
MESSAGE
BKR 1 ARC AMP
EVENTS: Disabled
Range: Disabled, Enabled
