6-6 L30 Line Current Differential System GE Multilin
6.2 STATUS 6 ACTUAL VALUES
6
b) STATISTICS
PATH: ACTUAL VALUES  STATUS  REMOTE DEVICES STATISTICS  REMOTE DEVICE 1(16)
Statistical data (two types) for up to 16 programmed remote devices is shown here.
The STNUM number is obtained from the indicated remote device and increments whenever a change of state of at least
one item occurs in the GSSE/GOOSE message. The SQNUM number is obtained from the indicated remote device and
increments whenever a GSSE/GOOSE message, without a state change, is sent. When the GSSE/GOOSE message
trasmits a state change, the
SQNUM resets to 0. This number rolls over to zero when a count of 4,294,967,295 is incre-
mented.
6.2.10 CHANNEL TESTS
PATH: ACTUAL VALUES  STATUS  CHANNEL TESTS
The status information for two channels is shown here. A brief description of each actual value is below:
 REMOTE DEVICE 1

REMOTE DEVICE 1
StNum: 0
MESSAGE
REMOTE DEVICE 1
SqNum: 0
 CHANNEL TESTS

CHANNEL 1
STATUS: n/a
Range: n/a, FAIL, OK
MESSAGE
CHANNEL 1 LOST
PACKETS: 0
Range: 0 to 65535 in steps of 1. Reset count to 0 through
the COMMANDS  CLEAR RECORDS menu.
MESSAGE
CHANNEL 1 LOCAL
LOOPBCK STATUS: n/a
Range: n/a, FAIL, OK
MESSAGE
CHANNEL 1 REMOTE
LOOPBCK STATUS: n/a
Range: n/a, FAIL, OK
MESSAGE
CHANNEL 1
LOOP DELAY: 0.0 ms
MESSAGE
CHANNEL 1 ASYMMETRY:
+0.0 ms
Range: –10 to 10 ms in steps of 0.1
MESSAGE
CHANNEL 2
STATUS: n/a
Range: n/a, FAIL, OK
MESSAGE
CHANNEL 2 LOST
PACKETS: 0
Range: 0 to 65535 in steps of 1. Reset count to 0 through
the COMMANDS  CLEAR RECORDS menu.
MESSAGE
CHANNEL 2 LOCAL
LOOPBCK STATUS: n/a
Range: n/a, FAIL, OK
MESSAGE
CHANNEL 2 REMOTE
LOOPBCK STATUS: n/a
Range: n/a, FAIL, OK
MESSAGE
CHANNEL 2
LOOP DELAY: 0.0 ms
MESSAGE
CHANNEL 2 ASYMMETRY:
+0.0 ms
Range: –10 to 10 ms in steps of 0.1
MESSAGE
VALIDITY OF CHANNEL
CONFIGURATION: n/a
Range: n/a, FAIL, OK
MESSAGE
PFLL
STATUS: n/a
Range: n/a, FAIL, OK
