6-4 L30 Line Current Differential System GE Multilin
6.2 STATUS 6 ACTUAL VALUES
6
6.2.4 REMOTE DOUBLE-POINT STATUS INPUTS
PATH: ACTUAL VALUES  STATUS  REMOTE DPS INPUTS
The present state of the remote double-point status inputs is shown here. The actual values indicate if the remote double-
point status inputs are in the on (close), off (open), intermediate, or bad state.
6.2.5 DIRECT INPUTS
PATH: ACTUAL VALUES  STATUS  DIRECT INPUTS
The present state of the direct inputs from communications channels 1 and 2 are shown here. The state displayed will be
that of the remote point unless channel 1 or 2 has been declared to have “failed”, in which case the value shown is the pro-
grammed default state defined in the SETTINGS  INPUTS/OUTPUTS  DIRECT  DIRECT INPUTS menu.
6.2.6 CONTACT OUTPUTS
PATH: ACTUAL VALUES  STATUS  CONTACT OUTPUTS
 REMOTE DPS INPUTS

REMOTE DPS INPUT 1
STATUS: Bad
Range: On, Off, Intermediate, Bad
MESSAGE
REMOTE DPS INPUT 2
STATUS: Bad
Range: On, Off, Intermediate, Bad
↓
MESSAGE
REMOTE DPS INPUT 5
STATUS: Bad
Range: On, Off, Intermediate, Bad
 DIRECT INPUTS

DIRECT INPUT 1-1:
Off
Range: On, Off
MESSAGE
DIRECT INPUT 1-2:
Off
Range: On, Off
↓
MESSAGE
DIRECT INPUT 1-8:
Off
Range: On, Off
MESSAGE
DIRECT INPUT 2-1:
Off
Range: On, Off
MESSAGE
DIRECT INPUT 2-2:
Off
Range: On, Off
↓
MESSAGE
DIRECT INPUT 2-8:
Off
Range: On, Off
 CONTACT OUTPUTS

Cont Op 1
Off
Range: On, Off, VOff, VOn, IOn, IOff
MESSAGE
Cont Op 2
Off
Range: On, Off, VOff, VOn, IOn, IOff
↓
MESSAGE
Cont Op xx
Off
Range: On, Off, VOff, VOn, IOn, IOff
