GE Multilin L30 Line Current Differential System 2-9
2 PRODUCT DESCRIPTION 2.2 ORDER CODES
2
2.2ORDER CODES 2.2.1 OVERVIEW
The L30 is available as a 19-inch rack horizontal mount or reduced-size (¾) vertical unit and consists of the following mod-
ules: power supply, CPU, CT/VT, contact input and output, transducer input and output, and inter-relay communications.
Each of these modules can be supplied in a number of configurations specified at the time of ordering. The information
required to completely specify the relay is provided in the following tables (see chapter 3 for full details of relay modules).
Order codes are subject to change without notice. See the ordering page at
http://www.gegridsolutions.com/multilin/order.htm
for the latest options.
The order code structure is dependent on the mounting option (horizontal or vertical) and the type of CT/VT modules
(enhanced diagnostic CT/VT modules or HardFiber
TM
process bus modules). The order code options are described in the
following sub-sections.
2.2.2 ORDER CODES WITH ENHANCED CT/VT MODULES
The order codes for the horizontal mount units are shown below.
Table 2–4: L30 ORDER CODES (HORIZONTAL UNITS)
L30 - * ** - * * * - F ** - H ** - L ** - N ** - S ** - U ** - W/X ** Full Size Horizontal Mount
BASE UNIT L30||||||||||| |Base Unit
CPU T | | | | | | | | | | | RS485 and Three Multi-mode fiber 100Base-FX (SFP with LC)
U | | | | | | | | | | | RS485 and Two Multi-mode fiber 100Base-FX (SFP with LC), One 10/100Base-T (SFP with RJ45)
V | | | | | | | | | | | RS485 and Three 10/100Base-T (SFP with RJ45)
SOFTWARE 00 | | | | | | | | | | No software options
03 | | | | | | | | | | IEC 61850
06 | | | | | | | | | | One phasor measurement unit (PMU)
07 | | | | | | | | | | IEC 61850 and one phasor measurement unit (PMU)
18 | | | | | | | | | | Synchrocheck, three-pole autoreclose
19 | | | | | | | | | | Synchrocheck, three-pole autoreclose, one phasor measurement unit (PMU)
24 | | | | | | | | | | In-zone transformer protection
25 | | | | | | | | | | In-zone transformer protection and IEC 61850
26 | | | | | | | | | | In-zone transformer protection and one phasor measurement unit (PMU)
27 | | | | | | | | | | In-zone transformer protection, IEC 61850, and one phasor measurement unit (PMU)
A0 | | | | | | | | | | CyberSentry Lvl 1
A3 | | | | | | | | | | CyberSentry Lvl 1 and IEC 61850
A6 | | | | | | | | | | CyberSentry Lvl 1 and phasor measurement unit (PMU)
A7 | | | | | | | | | | CyberSentry Lvl 1 and IEC 61850 and phasor measurement unit (PMU)
AI | | | | | | | | | | CyberSentry Lvl 1 and three-pole autoreclose and synchrocheck
AJ | | | | | | | | | | CyberSentry Lvl 1 and three-pole autoreclose and synchrocheck and one PMU
AO | | | | | | | | | | CyberSentry Lvl 1 and In-zone transformer protection
AP | | | | | | | | | | CyberSentry Lvl 1 and IEC 61850 and In-zone transformer protection
AQ | | | | | | | | | | CyberSentry Lvl 1 and phasor measurement unit (PMU) and In-zone transformer protection
AR | | | | | | | | | | CyberSentry Lvl 1 and IEC 61850 and (PMU) and In-zone transformer protection
B0 | | | | | | | | | | IEEE 1588
B3 | | | | | | | | | | IEEE 1588 and IEC 61850
B6 | | | | | | | | | | IEEE 1588 and phasor measurement unit (PMU)
B7 | | | | | | | | | | IEEE 1588 and IEC 61850 and phasor measurement unit (PMU)
BI | | | | | | | | | | IEEE 1588 and three-pole autoreclose and synchrocheck
BJ | | | | | | | | | | IEEE 1588 and three-pole autoreclose and synchrocheck and one PMU
BO | | | | | | | | | | IEEE 1588 and In-zone transformer protection
BP | | | | | | | | | | IEEE 1588 and IEC 61850 and In-zone transformer protection
BQ | | | | | | | | | | IEEE 1588 and phasor measurement unit (PMU) and In-zone transformer protection
BR | | | | | | | | | | IEEE 1588 and IEC 61850 and (PMU) and In-zone transformer protection
C0 | | | | | | | | | | Parallel Redundancy Protocol (PRP)
C3 | | | | | | | | | | PRP and IEC 61850
C6 | | | | | | | | | | PRP and PMU
C7 | | | | | | | | | | PRP, IEC 61850, and PMU
CI | | | | | | | | | | PRP, three-pole autoreclose, synchrocheck
CJ | | | | | | | | | | PRP, three-pole autoreclose, PMU, synchrocheck
CO | | | | | | | | | | PRP and in-zone transformer protection
CP | | | | | | | | | | PRP, in-zone transformer protection, and IEC 61850
CQ | | | | | | | | | | PRP, in-zone transformer protection, and PMU
CR | | | | | | | | | | PRP, in-zone transformer protection, IEC 61850, and PMU
D0 | | | | | | | | | | IEEE 1588 and CyberSentry Lvl 1
D3 | | | | | | | | | | IEEE 1588 and CyberSentry Lvl 1 and IEC 61850
D6 | | | | | | | | | | IEEE 1588 and CyberSentry Lvl 1 and phasor measurement unit (PMU)
D7 | | | | | | | | | | IEEE 1588 and CyberSentry Lvl 1 and IEC 61850 and phasor measurement unit (PMU)
DI | | | | | | | | | | IEEE 1588 and CyberSentry Lvl 1 and three-pole autoreclose and synchrocheck
DJ | | | | | | | | | | IEEE 1588 and CyberSentry Lvl 1 and three-pole autoreclose and synchrocheck and PMU
DO | | | | | | | | | | IEEE 1588 and CyberSentry Lvl 1 and In-zone transformer protection
DP | | | | | | | | | | IEEE 1588 and CyberSentry Lvl 1 and IEC 61850 and In-zone transformer protection
DQ | | | | | | | | | | IEEE 1588 and CyberSentry Lvl 1 and one PMU and In-zone transformer protection
DR | | | | | | | | | | IEEE 1588 and CyberSentry Lvl 1 and IEC 61850 and PMU and In-zone transformer protection
E0 | | | | | | | | | | IEEE 1588 and PRP
E3 | | | | | | | | | | IEEE 1588, PRP, IEC 61850
E6 | | | | | | | | | | IEEE 1588, PRP, and PMU
E7 | | | | | | | | | | IEEE 1588, PRP, IEC 61850, and PMU
EI | | | | | | | | | | IEEE 1588, PRP, three-pole autoreclose, synchrocheck
EJ | | | | | | | | | | IEEE 1588, PRP, three-pole autoreclose, PMU, synchrocheck
EO | | | | | | | | | | IEEE 1588, PRP, and in-zone transformer protection
EP | | | | | | | | | | IEEE 1588, PRP, in-zone transformer protection, and IEC 61850
EQ | | | | | | | | | | IEEE 1588, PRP, in-zone transformer protection, and PMU
ER | | | | | | | | | | IEEE 1588, PRP, in-zone transformer protection, IEC 61850, and PMU
F0 | | | | | | | | | | PRP and CyberSentry Lvl 1
F3 | | | | | | | | | | PRP, CyberSentry Lvl 1, and IEC 61850
F6 | | | | | | | | | | PRP, CyberSentry Lvl 1, and PMU
F7 | | | | | | | | | | PRP, CyberSentry Lvl 1, IEC 61850, and PMU
FI | | | | | | | | | | PRP, CyberSentry Lvl 1, three-pole autoreclose, synchrocheck
FJ | | | | | | | | | | PRP, CyberSentry Lvl 1, three-pole autoreclose, PMU, synchrocheck
FO | | | | | | | | | | PRP, CyberSentry Lvl 1, in-zone transformer protection
FP | | | | | | | | | | PRP, CyberSentry Lvl 1, in-zone transformer protection, and IEC 61850
FQ | | | | | | | | | | PRP, CyberSentry Lvl 1, in-zone transformer protection, and PMU
FR | | | | | | | | | | PRP, CyberSentry Lvl 1, in-zone transformer protection, IEC 61850, and PMU
G0 | | | | | | | | | | IEEE 1588, PRP, and CyberSentry Lvl 1
G3 | | | | | | | | | | IEEE 1588, PRP, CyberSentry Lvl 1, and IEC 61850
G6 | | | | | | | | | | IEEE 1588, PRP, CyberSentry Lvl 1, and PMU
G7 | | | | | | | | | | IEEE 1588, PRP, CyberSentry Lvl 1, IEC 61850, and PMU
GI | | | | | | | | | | IEEE 1588, PRP, CyberSentry Lvl 1, three-pole autoreclose, synchrocheck
GJ | | | | | | | | | | IEEE 1588, PRP, CyberSentry Lvl 1, three-pole autoreclose, PMU, synchrocheck
GO | | | | | | | | | | IEEE 1588, PRP, CyberSentry Lvl 1, in-zone transformer protection
GP | | | | | | | | | | IEEE 1588 PRP, CyberSentry Lvl 1, in-zone transformer protection, and IEC 61850
GQ | | | | | | | | | | IEEE 1588, PRP, CyberSentry Lvl 1, in-zone transformer protection, and PMU
GR | | | | | | | | | | IEEE 1588, PRP, CyberSentry Lvl 1, in-zone transformer protection, IEC 61850, and PMU
J0 | | | | | | | | | | IEC 60870-5-103
J3 | | | | | | | | | | IEC 60870-5-103 + IEC 61850
