6-8 L30 Line Current Differential System GE Multilin
6.2 STATUS 6 ACTUAL VALUES
6
The display shows both the current position and the full range. The current position only (an integer from 0 through 7) is the
actual value.
6.2.13 FLEX STATES
PATH: ACTUAL VALUES  STATUS  FLEX STATES
There are 256 FlexState
TM
bits available. The second line value indicates the state of the given FlexState bit.
6.2.14 IEC 61850 GOOSE INTEGERS
PATH: ACTUAL VALUES  STATUS  IEC 61850 GOOSE UINTEGERS
The L30 Line Current Differential System is provided with optional IEC 61850 communications capability.
This feature is specified as a software option at the time of ordering. See the Order Codes section in chap-
ter 2 for details.
The IEC 61850 GGIO5 integer input data points are displayed in this menu. The GGIO5 integer data values are received
via IEC 61850 GOOSE messages sent from other devices.
6.2.15 ETHERNET
PATH: ACTUAL VALUES  STATUS  ETHERNET
These values indicate the status of the first, second, and third Ethernet links.
 FLEX STATES

PARAM 1: Off
Off
Range: Off, On
MESSAGE
PARAM 2: Off
Off
Range: Off, On
↓
MESSAGE
PARAM 256: Off
Off
Range: Off, On
 IEC 61850
 GOOSE UINTEGERS
UINT INPUT 1
0
MESSAGE
UINT INPUT 2
0
↓
MESSAGE
UINT INPUT 16
0
 ETHERNET

ETHERNET PRI LINK
STATUS: Fail
Range: Fail, OK
MESSAGE
ETHERNET SEC LINK
STATUS: Fail
Range: Fail, OK
MESSAGE
ETHERNET TRD LINK
STATUS: Fail
Range: Fail, OK
