GE Multilin L30 Line Current Differential System C-25
APPENDIX C C.6 ACSI CONFORMANCE
C
DATA SET (CLAUSE 12)
S12 GetDataSetValues TP M Yes
S13 SetDataSetValues TP O
S14 CreateDataSet TP O
S15 DeleteDataSet TP O
S16 GetDataSetDirectory TP O Yes
SETTING GROUP CONTROL (CLAUSE 16)
S18 SelectActiveSG TP O
S19 SelectEditSG TP O
S20 SetSGValues TP O
S21 ConfirmEditSGValues TP O
S22 GetSGValues TP O
S23 GetSGCBValues TP O
REPORTING (CLAUSE 17)
BUFFERED REPORT CONTROL BLOCK (BRCB)
S24 Report TP c6 Yes
S24-1 data-change (dchg) Yes
S24-2 qchg-change (qchg)
S24-3 data-update (dupd)
S25 GetBRCBValues TP c6 Yes
S26 SetBRCBValues TP c6 Yes
UNBUFFERED REPORT CONTROL BLOCK (URCB)
S27 Report TP c6 Yes
S27-1 data-change (dchg) Yes
S27-2 qchg-change (qchg)
S27-3 data-update (dupd)
S28 GetURCBValues TP c6 Yes
S29 SetURCBValues TP c6 Yes
LOGGING (CLAUSE 17)
LOG CONTROL BLOCK
S30 GetLCBValues TP M
S31 SetLCBValues TP M
LOG
S32 QueryLogByTime TP M
S33 QueryLogByEntry TP M
S34 GetLogStatusValues TP M
GENERIC SUBSTATION EVENT MODEL (GSE) (CLAUSE 18, ANNEX C)
GOOSE-CONTROL-BLOCK (CLAUSE 18)
S35 SendGOOSEMessage MC c8 Yes
S36 GetReference TP c9
S37 GetGOOSEElementNumber TP c9
S38 GetGoCBValues TP O Yes
S39 SetGoCBValues TP O Yes
GSSE-CONTROL-BLOCK (ANNEX C)
S40 SendGSSEMessage MC c8 Yes
S41 GetReference TP c9
S42 GetGSSEElementNumber TP c9
S43 GetGsCBValues TP O Yes
SERVICES AA: TP/MC SERVER/
PUBLISHER
UR FAMILY
