Table 3-4: System Parameters
Controls Available on Freeze or Recall
• Automatic Optimization
• SRI-HD
• B/M Mode (Gray Map; TGC, Colorized B and M;
Frame Average [Loops only]; Dynamic Range)
• Anatomical M-Mode
• Read Zoom
• Base Line Shift
• Sweep Speed
• PW-Mode (Gray Map; Post Gain; Baseline Shift;
Sweep Speed; Invert Spectral Waveform;
Compression; Rejection, Colorized Spectrum;
Display Format; Angle Correct; Quick Angle
Correct, Auto Angle Correct)
• Color Flow (Overall Gain [Loops and Stills]; Color
Map; Transparency Map; Frame Averaging [Loops
only]; Flash Suppression, CFM Display Threshold;
Spectral Invert for Color/Doppler)
• Anatomical M-Mode on CINE Loop
Controls Available While “Live”
• Write zoom
• B/M-Mode (Gain; TGC; Dynamic Range; Acoustic
Output; Transmission Focus Position;
Transmission Focus Number; Line Density
Control; Sweep Speed for M-Mode; # of Angles for
CrossXBeam)
• PW-Mode (Gain; Dynamic Range; Acoustic
Output; Transmission Frequency; PRF; Wall Filter;
Spectral Averaging; Sample Volume Gate for
PW-Mode Length and Depth; Velocity Scale)
• Color Flow (CFM Gain; CFM Velocity Range;
Acoustic Output; Wall Echo Filter; Packet Size;
Frame Rate Control; CFM Spatial Filter; CFM
Frame Averaging; CFM Line Resolution;
Frequency/Velocity Baseline Shift)
Scanning Parameters
• Displayed Imaging Depth: 2 - 33 cm
• Minimum Depth of Field: 0 - 2 cm (Zoom) (probe
dependent)
• Maximum Depth of Field: 0 - 33 cm (probe
dependent)
• Continuous Dynamic Receive Focus / Continuous
Dynamic Receive Aperture
• Adjustable Dynamic Range
• Adjustable Field of View [FOV]
• Image Reverse: Right/ Left
• Image Rotation: 0°, 180°
Image Storage
• On-board database of patient information from
past exams
• Storage Formats:
• DICOM - compressed/ uncompressed, single/
multiframe, with/ without Raw Data
• Export JPEG,JPEG2000, WMV (MPEG 4),
and AVI formats
• Storage Devices:
• USB Flash Device: 64MB to 4GB (for
exporting individual images/clips)
• CD-RW storage: 700MB
• DVD storage: -R (4.7GB)
• Hard Drive Image Storage: ~50GB
• Compare old images with current exam
• Reload of archived data sets
CINE Memory/Image Memory
• Selectable CINE Sequence for CINE Review
• Measurements/Calculations & Annotations on
CINE Playback
• Scrolling timeline memory
• Dual Image CINE Display
• Quad Image CINE Display
• CINE Gauge and CINE Image Number Display
• CINE Review Loop
• CINE Review Speed
