8-94 Section 8-6 - Mechanical Parts- Replacement Procedures
D
IRECTION 5771498-100, REVISION 6 VENUE™ SERVICE MANUAL
PRELIMINARY
5.) Install the riser cover and secure with four screws.
6.) Install scanner arm.
7.) Refit the following covers: Lower Front eTower cover, Left Side eTower cover, Right Side eTower
cover, Riser Thermal Cover, Upper Front eTower Cover and RS Probe cover.
8.) Install the cockpit (monitor).
9.) Install all accessories.
10.)Turn ON power to the system.
• Arm Installation Procedure
• Upper eTower Front Cover Installation Procedure
• Right Side eTower Cover Installation Procedure
• Left Side eTower Cover Installation Procedure
• Riser Thermal Cover Installation Procedure
• Lower Front eTower Cover Installation Procedure
• RS Probe Cover Installation Procedure
• Cockpit (Monitor) Installation Procedure
• Accessories - Replacement Procedures
Perform the checks listed in Riser Replacement Procedure on page 8-218
