IRECTION 5771498-100, REVISION 6 VENUE™ SERVICE MANUAL

Chapter 3 - System Setup 3-19

PRELIMINARY

3-4-3-2 Front View of the Venue™ Ultrasound Unit

Figure 3-22 Front View of the Venue™ Ultrasound Scanner

# Item

Cockpit (monitor):

Tilts up and down and swivels left and right.

2 eTower:

3 Basket holders

Caster:

(1x front) with free movement and no locking.

Swivel and full lock caster:

(1x front)

6 Front Handle

7 Auxiliary monitor
