12 ADV200 • Quick start up guide
2.1 Drive type designation
The main technical characteristic of the drive are showed in the product code and
in the nameplate. I.e. product code:
ADV 1 040 -K B X -4 -XX YY -DC -SI -IT
IT = IT Network configuration
Safety card EXP-SFTy-ADV included
DC bus power supply version
Parallel version only:
XX : MS = MASTER
SL = SLAVE
YY : 04 = 400.0 kW
05 = 500.0 kW
06 = 630.0 kW
07 = 710.0 kW
09 = 900.0 kW
10 = 1000.0 kW
Rated voltage :
4 = 400 Vac 4A = 460 Vac
Software:
X = standard
Braking unit:
X = non included
B = included
Keypad:
X = not included
K = included
Drive power, in kW:
007 = 0.75 kW
015 = 1.5 kW
022 = 2.2 kW
030 = 3.0 kW
040 = 4.0 kW
055 = 5.5 kW
075 = 7.5 kW
110 = 11.0 kW
150 = 15.0 kW
185 = 18.5 kW
220 = 22.0 kW
300 = 30.0 kW
370 = 37.0 kW
450 = 45.0 kW
550 = 55.0 kW
750 = 75.0 kW
900 = 90.0 kW
1100 = 110.0 kW
1320 = 132.0 kW
1600 = 160.0 kW
2000 = 200.0 kW
2500 = 250.0 kW
3150 = 315.0 kW
3551 = 355.0 kW
Mechanical drive sizes:
1 = size 1
2 = size 2
3 = size 3
4 = size 4
5 = size 5
6 = size 6
7 = size 7
Drive ADV200 series
Identication Nameplate
Type :ADV1040 -KBX S/N: 07012345
Inp: 400Vac-480Vac (Fctry set=400) 50/60Hz 3Ph
11.1A@400Vac 10A@480Vac
Out :0-480Vac 500Hz 3Ph 4kW@400Vac 5Hp@460Vac
9.5A @400V Ovld.150%-60s 8.55A@460V Ovld.150%-60s
13 A @400V Ovld.110%-60s 11.7A@460V Ovld.110%-60s
Drive model
Serial number
Input (mains supply, frequency, AC Input
Current at constant torque)
Output (Output voltage, frequency, power,
current, CT and VT overloads)
Approvals
IND. CONT. EQ.
31KF
Gefran S.p.Avia G.Carducci, 24
I-21040-Gerenzano, VA
Firmware & cards revision level nameplate
