10.1.2 External fuses of the power section DC input side (F2)
The following fuses must be used with an external DC power supply or regenerative
converter (for further details refer to the converter instruction manual):
Sizes
F2 - External fuses for DC input side
EUROPE AMERICA
Type Code Type Code
1007 ... 1022
URZ 50 124 06.11
FWP-10A14Fa
S7G49
URZ 50 124 06.11
FWP-10A14Fa
S7G49
1030 - 1040
FWP-20A14F S7G48 FWP-20A14F
S7G48
2055 FWP-30A14F S7I50 FWP-30A14F S7I50
2075
FWP-40B S7G52 FWP-40B S7G52
2110
FWP-50B S7G53 FWP-50B
S7G53
3150 ... 3220
S00C+/üf1/80A/690V F4EAF FWP-80B
S7G54
4300
S00C+/üf1/100A/690V F4EAG FWP-100B
S7G55
4370
S00C+/üf1/125A/690V F4EAJ FWP-150A
S7G56
4450 S00C+/üf1/160A/690V F4EAL FWP-150A S7G56
5550
S00üf1/80/200A/690V F4G23 FWP-200A S7G58
5750 S1üf1/110/250A/690V F4G28 FWP-250A S7G59
5900 S1üf1/110/315A/690V F4G30 FWP-350A S7G61
61100 S2üf1/110/400A/690V F4G34 FWP-400A S7G62
61320 - 71600 S2üf1/110/500A/690V F4E30
FWP-500A
S7G63
72000 S2üf1/110/630A/690V F4E31
FWP-600A
S7G65
72500
S3üf1/110/800A/690V F4H02 FWP-800A S7813
73150 - 73551 S3üf1/110/1000A/690V F4H03 FWP-1000A S7812
400 kW
ADV-72000-KXX-4-MS 04 S2üf1/110/630A/690V F4E31 FWP-600A S7G65
ADV-72000-XXX-4-SL S2üf1/110/630A/690V F4E31 FWP-600A S7G65
500 kW
ADV-72500-KXX-4-MS 05 S3üf1/110/800A/690V F4H02 FWP-800A S7813
ADV-72500-XXX-4-SL S3üf1/110/800A/690V F4H02 FWP-800A S7813
630 kW
ADV-73150-KXX-4-MS 06 S3üf1/110/1000A/690V F4H03 FWP-1000A S7812
ADV-73150-XXX-4-SL S3üf1/110/1000A/690V F4H03 FWP-1000A S7812
710 kW
ADV-73551-KXX-4-MS 07 S3üf1/110/1000A/690V F4H03 FWP-1000A S7812
ADV-73551-XXX-4-SL S3üf1/110/1000A/690V F4H03 FWP-1000A S7812
900 kW
ADV-73150-KXX-4-MS 09 S3üf1/110/1000A/690V F4H03 FWP-1000A S7812
ADV-73150-XXX-4-SL S3üf1/110/1000A/690V F4H03 FWP-1000A S7812
ADV-73150-XXX-4-SL S3üf1/110/1000A/690V F4H03 FWP-1000A S7812
1 MW
ADV-73551-KXX-4-MS 10 S3üf1/110/1000A/690V F4H03 FWP-1000A S7812
ADV-73551-XXX-4-SL S3üf1/110/1000A/690V F4H03 FWP-1000A S7812
ADV-73551-XXX-4-SL S3üf1/110/1000A/690V F4H03 FWP-1000A S7812
Note! For size 7 only, adaptation for internal mounting of fuses (DC side) on request.
The technical data of the fuses, e.g. dimensions, weights, heat dissipation, auxiliary contactors, are reported
in the corresponding manufacturer data sheets.
URZ (SIBA), FWP (Bussmann), S.. (Jean Müller).
