174 ADV200 • Quick start up guide
10.5 Braking resistor (optional)
Recommended resistors for use with internal braking unit (except ADV200-DC
models):
Sizes
List and technical data of standard external resistors
Resistor type Code
Max Overload
energy, 1”- duty-
cycle 10%
E
br
(kJ)
Max Overload
energy, 30”- duty-
cycle 25%
E
br
(kJ)
Braking resis-
tor nominal
power
P
nbr
(W)
Resistance
value
R
br (
Ω)
Enclosure
1007 RF 220 T 100R S8T0CE 1.5 11 220 100 IP44
1015 RF 220 T 100R S8T0CE 1.5 11 220 100 IP44
1022 RF 300 DT 100R S8T0CB 2.5 19 300 100 IP44
1030 RF 300 DT 100R S8T0CB 2.5 19 300 100 IP44
1040 RFPD 750 DT 100R S8SY4 7.5 38 750 100 IP44
2055 RFPD 750 DT 68R S8T0CD 7.5 38 750 68 IP44
2075 RFPD 900 DT 68R S8SY5 9 48 900 68 IP44
2110 RFPD 1100 DT 40R S8SY6 11 58 1100 40 IP44
3150 RFPR 1900 D 28R S8SZ5 19 75 1500 28 IP44
3185 BRT4K0-15R4 S8T00G 40 150 4000 15.4 IP20
3220 BRT4K0-15R4 S8T00G 40 150 4000 15.4 IP20
4300 BRT4K0-11R6 S8T00H 40 150 4000 11.6 IP20
4370 BRT4K0-11R6 S8T00H 40 150 4000 11.6 IP20
4450 BRT8K0-7R7 S8T00I 40 150 8000 7.7 IP20
5550 BRT8K0-7R7 S8T00I 40 150 8000 7.7 IP20
≥ 5750 and
ADV200-...-DC
External braking unit (BUy series, optional)
Resistor type Code Dimensions (Wx H x d) - mm Weights (kg)
RF 220 T 100R S8T0CE 300 x 27 x 36 0,5
RF 300 DT 100R S8T0CB 260 x 47 x 108 1,4
RFPD 750 DT 100R S8SY4 200 x 70 x 106 1,7
RFPD 750 DT 68R S8T0CD 200 x 70 x 106 1,7
RFPD 900 DT 68R S8SY5 260 x 70 x 106 2,2
RFPD 1100 DT 40R S8SY6 320 x 70 x 106 2,7
RFPR 1900 D 28R S8SZ5 365 x 75 x 100 4,2
BRT4K0-15R4 S8T00G 625 x 100 x 250 7,0
BRT4K0-11R6 S8T00H 625 x 100 x 250 7,0
BRT8K0-7R7 S8T00I 625 x 160 x 250 11,5
Braking resistors may be subject to unexpected overloads due to faults.
Resistors MUST be protected using thermal cutouts. These devices must not interrupt the
circuit in which the resistor is inserted but their auxiliary contact must cut off the power
supply to the power section of the drive. If the resistor requires a protection contact, this
must be used together with that of the thermal cutout.
A la suite de pannes, les résistances de freinage peuvent être sujettes à des surcharges impré-
vues. La protection des résistances au moyen de dispositifs de protection thermique est absolu-
ment capitale. Ces dispositifs ne doivent pas interrompre le circuit qui abrite la résistance, mais
leur contact auxiliaire doit couper l’alimentation du côté puissance du drive. Si la résistance
prévoit un contact de protection, ce dernier doit être utilisé conjointement à celui du dispositif de
protection thermique.
Warning!
