gefran ADV200 Series User Manual

ADV200 • Quick start up guide 171
Grid: 380V / 60Hz
Motor Power
4 poles IE2
Motor
Efficiency
Drive Size
Drive Output: Light Duty
RHF Passive Filter
Line
Input Current
@ 380V
Rated
Power
Rated
Current
Overload
Type (1) Current
[%] [kW] [A] [A] [A]
132 94.7 61100 132 250 RHF-A/B 217-380-60-20-A 217.0 219.4
160 94.9 61320 160 300 RHF-A/B 252-380-60-20-A 252.0 265.4
200 95.1 71600 200 385 RHF-A/B 325-380-60-20-A 325.0 331.0
250 95.1 72000 250 460 RHF-A/B 433-380-60-20-A 433.0 413.8
315 95.1 72500 315 590 2 x RHF-A/B 252-380-60-20-A 504.0 521.4
355 95.1 73150 355 650 2 x RHF-A/B 304-380-60-20-A 608.0 587.6
400 95.5 73551 400 730 (2) 2 x RHF-A/B 325-380-60-20-A 650.0 659.3
500 95.8 400 kW 500 870 2 x RHF-A/B 380-380-60-20-A 760.0 821.5
630 96 500 kW 630 1120 On request 975.0 1033.0
710 96.5 630 kW 710 1230 On request 1140.0 1158.1
800 96.7 710 kW 800 1380 On request 1299.0 1302.2
1000 96.7 900 kW 1000 1800 On request 1520.0 1627.8
1200 96.7 1 MW 1200 2050 On request 2165.0 1953.3
1500 96.7 1.35 MW 1650 2540 On request 2598.0 2441.6
1800 96.7 1.65 MW 1800 3100 On request 3031.0 2930.0
(1) RHF-A/B: RHF-A Models ... or RHF-B-... , RHF-AS/BS: RHF-AS Models ... or RHF-BS-...; see section 10.4.1.
(2) Overload 110% the Rated Current for 60s every 300s
(3) Reduced THDi performance due to part load
Grid: 460V / 60Hz - Motor voltage: 460V
Motor Power
4 poles IE2
Motor
Efficiency
Drive Size
Drive Output: Light Duty
RHF Passive Filter
Line
Input Current
@ 380V
Rated
Power
Rated
Current
Overload
Type (1) Current
[%] [kW] [A] [A] [A]
1.5 82.8 1007 1.5 3.9 RHF-A/B 6-460-60-20-A (3) 6.0 2.4
2.2 84.3 1015 2.2 5.2 RHF-A/B 6-460-60-20-A
(3) 6.0 3.4
3 85.5 1022 3 6.8 RHF-A/B 6-460-60-20-A 6.0 4.6
4 86.6 1030 4 8.6 RHF-A/B 6-460-60-20-A 6.0 6.0
5.5 87.7 1040 5.5 11.7 RHF-A/B 10-460-60-20-A 10.0 8.2
7.5 88.7 2055 7.5 14.9 RHF-A/B 14-460-60-20-A 14.0 11.0
11 89.8 2075 11 20.7 RHF-A/B 19-460-60-20-A 19.0 15.9
15 90.6 2110 15 27.9 RHF-A/B 25-460-60-20-A 25.0 21.5
18.5 91.2 3150 18.5 34.2 RHF-A/B 31-460-60-20-A 31.0 26.4
22 91.6 3185 22 41.4 RHF-A/B 31-460-60-20-A 31.0 31.2
30 92.3 3220 30 55.8 RHF-A/B 48-460-60-20-A 48.0 42.3
37 92.7 4300 37 67.5 (2) RHF-A/B 60-460-60-20-A 60.0 51.9
45 93.1 4370 45 78.3 RHF-A/B 73-460-60-20-A 73.0 62.8
55 93.5 4450 55 94.5 RHF-A/B 86-460-60-20-A 86.0 76.5
75 94 5550 75 135 RHF-A/B 118-460-60-20-A 118.0 103.7
90 94.2 5750 90 162 RHF-A/B 154-460-60-20-A 154.0 124.2
110 94.5 5900 110 189 RHF-A/B 154-460-60-20-A 154.0 151.4
132 94.7 61100 132 225 RHF-A/B 183-460-60-20-A 183.0 181.2
160 94.9 61320 160 270 RHF-A/B 231-460-60-20-A 231.0 219.2
200 95.1 71600 200 347 RHF-A/B 291-460-60-20-A 291.0 273.5
250 95.1 72000 250 414 RHF-A/B 355-460-60-20-A 355.0 341.8
315 95.1 72500 315 531 RHF-A/B 436-460-60-20-A 436.0 430.7
355 95.1 73150 355 585 2 x RHF-A/B 291-460-60-20-A 582.0 485.4
400 95.5 73551 400 657 2 x RHF-A/B 291-460-60-20-A 582.0 544.6
500 95.8 400 kW 500 783 2 x RHF-A/B 355-460-60-20-A 710.0 678.7
630 96 500 kW 630 1008 2 x RHF-A/B 436-460-60-20-A 872.0 853.3
