HP Integrity Superdome X User Manual

Server blade port Compute enclosure
interconnect bay
Interconnect bay label
Mezzanine 1 port 4 4
Mezzanine 2 port 1 5
Mezzanine 2 port 2 6
Mezzanine 2 port 3 7
Mezzanine 2 port 4 8
Mezzanine 3 port 1 7
Mezzanine 3 port 2 8
Mezzanine 3 port 3 5
Mezzanine 3 port 4 6
NOTE:
For information on the location of LEDs and ports on individual interconnect modules, see the
documentation that ships with the interconnect module.
More information
• Integrity Superdome X QuickSpecs
Server blade overview
Product Processors DIMM slots Supported
DIMM size
PCIe I/O
Mezzanine
card capacity
PCI I/O
FlexLOM card
capacity
BL920s Gen8
BL920s Gen9
2 48 16 GB and 32
GB (Gen8)
16 GB, 32 GB,
and 64 GB
(Gen9)
3 2
20 Server blade overview

HP Integrity Superdome X Specifications

General

Brand	HP
Model	Integrity Superdome X
Category	Server
Language	English
